Details
Post Hole Digger
Description
Post Hole Digger (PHD) is tractor operated equipment to dig pits in agriculture or any other land with less time and effort.
More suitable for Agriculture & Industrial Application like:
- Plantation of saplings like Mango, coconut, pomegranate, teak, lemon etc.
-
Erecting Fencing poles
-
Erecting electric poles
-
Road signs
-
Marking stones
Advantages
Manual digging pits is expensive, laborious and time consuming particularly when required to dig holes in mass numbers.
Using Agrowave PHD, pit can be made:
-
In less than a minute,
-
Up to a depth of 3 feet, with well defined circumference and neater pit.
-
Removed soil will be placed around the pit which becomes easy to fill the pit back after plantation or erection work done.
Technical Specifications & Ordering Details:
Model |
JSPHD-1000 |
540 PTO RPM |
174 |
Max Depth Of Hole (mm/inch) |
900/ 35.43 |
Digger Weight (kg/ lbs) |
185/ 407 |
Drill diameter (mm/ inch) |
152/6 |
229/9 |
305/12 |
457/18 |
609/24 |
762/30 |
914/36 |
Auger Weight (kg/lbs) |
15/33 |
25/55 |
35/77 |
42/92 |
53/117 |
65/143 |
78/172 |
Gross Weight (kg/lbs) |
190/418 |
210/462 |
220/484 |
227/500 |
238/524 |
250/550 |
263/579 |
LxWxH (mm) |
2180x854x2908 |
Additional Features
