Superheated Water Spray Sterilizer

More Views

Code:

Superheated Water Spray Sterilizer

Based on the principle of moist-heat sterilization under counter pressure, Superheated Water Spray Sterilizers are designed to meet terminal sterilization requirements in pharmaceutical industry. These Superheated Sterilizers are fitted with water recirculation through sanitary pump and spray system to heat up and cool down the products to be sterilized. These units are ideal for infusion products, blister packed products and large volumes of liquids sealed in glass or plastic containers.
We manufacture super heated water spray sterilizers focusing pharmaceutical industry in compliance with EN and DIN standards where applicable. Each unit has circular inner chamber and rectangular door. These units feature fully automatic control system; touch screen control panel and thermal printer enabling users to operate the machine in very convenient way.
In addition to our standard model and displayed sizes, our superheated water spray sterilizers can be custom designed. If you have specific requirements in dimensions, loading capacities or control systems, we can provide you exact machine at highly competitive price in India.

Features

Terminal sterilization of glassware and plastic bottles	High degree of operational flexibility
Follow cGMP requirements	Can compliant to EN and DIN standards
Chamber piping and fittings in AISI SS 316L	Uniform distribution of spray through nozzles
Recirculation through sanitary grade pump	High grade thermal insulation
Fitted with wide range of alarms and safety devices	Operation through PLC + HMI control system

Specifications:

Model	Chamber size (L x Dia.) mm	Steam consumption (Kg / cycle)	Water Consumption (Kg / cycle)	Cooling water consumption (Kg / cycle)	Compressed air consumption (m3 / cycle)
JBSTDKS10	3160 x Ø2000	650	1000	8000	12
JBSTDKS14	4260 x Ø2000	800	1300	12000	17
JBSTDKS17	5260 x Ø2000	1000	1600	15000	20
JBSTDKS22	6790 x Ø2000	1200	2000	20000	25
JBSTDKS31	9860 x Ø2000	1700	3000	28000	34
JBSTDKS35	10980 x Ø2000	1850	3300	32000	39
JBSTDKS40	8360 x Ø2500	2100	3500	38000	45
Steam pressure	0.4 – 0.6 MPa
Design pressure	0.17 – 0.30 MPa
Water pressure	0.2 – 0.4 MPa
Working pressure	0.15 – 0.27 MPa
Compressed air pressure	0.5 – 0.7 MPa
Working Temperature	126°C
Optional	- Load rotation systems - Load / unloading trolley - Shelf trays - Shelf trolley

Description

Superheated Water Spray Sterilizer

Based on the principle of moist-heat sterilization under counter pressure, Superheated Water Spray Sterilizers are designed to meet terminal sterilization requirements in pharmaceutical industry. These Superheated Sterilizers are fitted with water recirculation through sanitary pump and spray system to heat up and cool down the products to be sterilized. These units are ideal for infusion products, blister packed products and large volumes of liquids sealed in glass or plastic containers.
We manufacture super heated water spray sterilizers focusing pharmaceutical industry in compliance with EN and DIN standards where applicable. Each unit has circular inner chamber and rectangular door. These units feature fully automatic control system; touch screen control panel and thermal printer enabling users to operate the machine in very convenient way.
In addition to our standard model and displayed sizes, our superheated water spray sterilizers can be custom designed. If you have specific requirements in dimensions, loading capacities or control systems, we can provide you exact machine at highly competitive price in India.

Features

Terminal sterilization of glassware and plastic bottles	High degree of operational flexibility
Follow cGMP requirements	Can compliant to EN and DIN standards
Chamber piping and fittings in AISI SS 316L	Uniform distribution of spray through nozzles
Recirculation through sanitary grade pump	High grade thermal insulation
Fitted with wide range of alarms and safety devices	Operation through PLC + HMI control system

Specifications:

Model	Chamber size (L x Dia.) mm	Steam consumption (Kg / cycle)	Water Consumption (Kg / cycle)	Cooling water consumption (Kg / cycle)	Compressed air consumption (m3 / cycle)
JBSTDKS10	3160 x Ø2000	650	1000	8000	12
JBSTDKS14	4260 x Ø2000	800	1300	12000	17
JBSTDKS17	5260 x Ø2000	1000	1600	15000	20
JBSTDKS22	6790 x Ø2000	1200	2000	20000	25
JBSTDKS31	9860 x Ø2000	1700	3000	28000	34
JBSTDKS35	10980 x Ø2000	1850	3300	32000	39
JBSTDKS40	8360 x Ø2500	2100	3500	38000	45
Steam pressure	0.4 – 0.6 MPa
Design pressure	0.17 – 0.30 MPa
Water pressure	0.2 – 0.4 MPa
Working pressure	0.15 – 0.27 MPa
Compressed air pressure	0.5 – 0.7 MPa
Working Temperature	126°C
Optional	- Load rotation systems - Load / unloading trolley - Shelf trays - Shelf trolley
