- Description
-
Details
We are one of the leading suppliers of 3.75 Digit Digital Multimeter (Auto Range) to our highly esteemed clients. These compressors are used in different industries to cater to the requirements of variegated clients. They are precisely engineered using premium quality raw material at our unit using hi tech machinery in conformity with the industrial prevailing norms and standards. 3.75 Digit Digital Multimeter (Auto Range) goes through various inspections to ensure that no compromise is done with its quality at any stage. They are available at pocket- friendly prices.Features:- LCD Display, Max. Upto 3999
- Auto operation
- Diode test, Triode test, Continuity test, Low Battery indication, Data hold,
- Auto power off, Function protection, Shock protection, Relative value
- Measurement, Frequency / Duty measurement
- Measure AC, DC Voltage & AC, DC Current , Resistance, Capacitance,Temperature, Frequency
Technical Specifications:DC Voltage range 400mV, 4V, 40V, 400V, 1000V Accuracy +(0.5% + 4 Digit) DC Current range 400microA, 4000microA, 40mA, 400mA, 10A Accuracy +(1% + 6 Digit) AC Voltage range 400mV, 4V, 40V , 400V, 750V Accuracy + (0.8% + 6 Digit) AC Current range 400microA, 4000microA,40mA, 400mA, 10A Accuracy +(1.5% + 10 Digit) Resistance range 400ohm, 4Kohm, 40Kohm, 400Kohm, 4Mohm, 40Mohm Accuracy + (0.8% + 4 Digit ) Capacitance range 4nF, 40nF, 400nF, 4microF, 200microF Accuracy + (2.5% + 6 Digit) Frequency 100Hz, 1000Hz, 100kHz, 1MHz, 30MHz Accuracy +( 0.5% + 4 Digit ) Temperature -40OC ~ 1000OC Accuracy +( 0.8% + 4 Digit) Input impedance 10Mohm Sampling Rate 3s AC Frequency Response 40 ~ 400Hz Power requirement Battery AA, 1.5V x 2nos Weight 400g Approx.
Standard Accessories:- Probes, Batteries,
- Instruction manual
Ordering Details:Catalogue No. Description LTM-5075 3.75 Digit Digital Multimeter (Auto Range) - Additional Information
-
