ADIABATIC BATCH REACTOR

ADIABATIC BATCH REACTOR

More Views

ADIABATIC BATCH REACTOR

Code:

DESCRIPTION:

CRE Lab- homogeneous

An adiabatic batch reactor is a closed system with no input and output streams. This reactor is operated under conditions like adiabatic (Temperature of Reaction Mass keep on changing), Perfectly mixed (composition of reaction mixture is uniform throughout), and constant volume (volume of the reaction mixture within the reactor remains constant, there is no appreciable change in the density of reaction mass). This set-up is used to study a catalytic homogeneous reaction under adiabatic condition.

The set-up consists of a Dewar flask of capacity 1 lit. fitted with a stirrer. The flask is double insulated by ceramic wool insulation. Temp. is measured by digital temp indicator. The whole setup is mounted on a rigid M.S. frame

EXPERIMENTATION:

To study the decomposition of Hydrogen Peroxide with water in presence of an Iodide catalyst.
To predict the degree of conversion from time-temperature data.

UTILITIES REQUIRED:

Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted.

TECHNICAL DETAILS:

Reactor	Material Stainless Steel, Capacity 1 Ltrs. (Approx) Insulated with Ceramic wool.
Stirrer	Teflon Impeller and Stainless Steel shaft coupled with FHP motor.
Control panel comprises of
Digital Temp. Indicator	0-199.9°C, RTD PT-100 type Temp.
Sensors	RTD PT-100 type
With Standard make on/off switch
An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus.
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.

Ordering Details:

Catalogue No.	Description
JICRE-009	ADIABATIC BATCH REACTOR

Description

Details

DESCRIPTION:

CRE Lab- homogeneous

An adiabatic batch reactor is a closed system with no input and output streams. This reactor is operated under conditions like adiabatic (Temperature of Reaction Mass keep on changing), Perfectly mixed (composition of reaction mixture is uniform throughout), and constant volume (volume of the reaction mixture within the reactor remains constant, there is no appreciable change in the density of reaction mass). This set-up is used to study a catalytic homogeneous reaction under adiabatic condition.

The set-up consists of a Dewar flask of capacity 1 lit. fitted with a stirrer. The flask is double insulated by ceramic wool insulation. Temp. is measured by digital temp indicator. The whole setup is mounted on a rigid M.S. frame

EXPERIMENTATION:

To study the decomposition of Hydrogen Peroxide with water in presence of an Iodide catalyst.
To predict the degree of conversion from time-temperature data.

UTILITIES REQUIRED:

Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted.

TECHNICAL DETAILS:

Reactor	Material Stainless Steel, Capacity 1 Ltrs. (Approx) Insulated with Ceramic wool.
Stirrer	Teflon Impeller and Stainless Steel shaft coupled with FHP motor.
Control panel comprises of
Digital Temp. Indicator	0-199.9°C, RTD PT-100 type Temp.
Sensors	RTD PT-100 type
With Standard make on/off switch
An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus.
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.

Ordering Details:

Catalogue No.	Description
JICRE-009	ADIABATIC BATCH REACTOR
