AXIAL FAN TEST RIG (Variable Speed with DC Motor)

AXIAL FAN TEST RIG (Variable Speed with DC Motor)

More Views

AXIAL FAN TEST RIG (Variable Speed with DC Motor)

Code:

DESCRIPTION:

This equipment comprises of a Axial Flow Fan coupled to a DC Motor. Power input to the DC Motor is varied by means of a Thyristor controlled DC Drive to vary the RPM of motor. A RPM Indicator with


Proximity sensor indicates the RPM of Axial Fan. A Pitot Tube with manometer is provided in the delivery line of Axial fan for static and dynamic and differential pressure measurement.


EXPERIMENTATION:

To find out the discharge, head and efficiency of the Axial Fan
To plot the graph Efficiency Vs Discharge
To plot the graph Discharge Vs Head

UTILITIES REQUIRED:

Electricity Supply: Single Phase, 220V AC, 50 Hz, 5-15 amp. Combined socket with earth
connection.
Floor Area : 2.5 x 0.75 m.

TECHNICAL DETAILS:

Axial Fan	Compatible Capacity.
Drive	1HP DC motor with Thyristor controlled DC Drive for variable speed.
Pitot Tube (with manometer)	For Static, Dynamic & Differential Pressure measurement.
Stop watch	Electronic
Control Panel Comprises of
RPM measurement	RPM Indicator with Proximity sensor.
Energy measurement	Electronic Energy meter, L&T make.
Standard make On/Off Switch, Mains Indicator, etc.
An ENGLISH instruction manual consisting of experimental procedures, block diagram etc. will be provided along with the Apparatus.
The whole set-up is well designed and arranged on a rigid structure painted with industrial PU Paint.

Ordering Details:

Catalogue No.	Description
JIHD-153	AXIAL FAN TEST RIG (Variable Speed with DC Motor)
