B.O.D. Incubator (Humidity Controlled) -121(HC)

More Views

Code:

B.O.D. Incubator (Humidity Controlled) -121(HC)

Application

Germinators are useful for seed testing, biological studies, forestry research works etc.
With a solid see thru double walled door and a full view inner plexi-glass door enables inspection and monitoring of inner chamber specimens without distributing the process temperature.
Excellent quality magnetic gum packing door gasket for external door.
User oriented design of shelves makes you adjust each space of shelves without difficulty.
Forced air circulation at triple walled back by durable coaxial blower, maintains optimum temperature uniformity and homogeneity.
High grade PUF Insulation between outer and inner chamber for minimal thermal losses.
Caster wheel mounted for easy portability.
Front double walled door is provided with lock and key arrangement.
Door operated illumination lamp is fitted inside the chamber for easy visibility.
Finned tube evaporator facilitates uniform and faster cooling effects.
Safety Thermostate to prevent overheating.

Constructional And Salient Features

Front double walled door is provided with lock and key arrangement.
Door operated illumination lamp is fitted inside the chamber for easy visibility.
Finned tube evaporator facilitates uniform and faster cooling effects.
Safety Thermostate to prevent overheating.

Technical Specifications:

MOC Outer: Powder coated CRC Steel Sheet or Stainless Steel
MOC Inner: Chamber and trays made of Stainless Steel (SS-304)
Type: Forced Convection Type
Freezer Compressor: Hermetically sealed air cooling compressor system
Temperature Range: 5^OC to 60^OC
Accuracy: + 1 ^OC
Humidity Creation: Humidity generation (Steam Type)
Humidity Range: 5% above ambient from 40% to 95% RH at cool temperature
Humidity Accuracy: +3% RH
Controller: Microprocessor based temperature Data Logger with 9 segments to enable users to control nine different variation and repetition of temperature and humidity according to its conditions.
Electric Supply: 220/230V AC, 50/60Hz

Ordering Information with specifications:

Options:

Cat. No.	Options
LI-11201/1	Exterior illumination with fluorescent tubes
LI-11201/2	0-24 hrs cyclic timer to control cyclic illumination conditions
LI-11201/3	Communication port with interface and data cable to download data to your PC.

Description

B.O.D. Incubator (Humidity Controlled) -121(HC)

Application

Germinators are useful for seed testing, biological studies, forestry research works etc.
With a solid see thru double walled door and a full view inner plexi-glass door enables inspection and monitoring of inner chamber specimens without distributing the process temperature.
Excellent quality magnetic gum packing door gasket for external door.
User oriented design of shelves makes you adjust each space of shelves without difficulty.
Forced air circulation at triple walled back by durable coaxial blower, maintains optimum temperature uniformity and homogeneity.
High grade PUF Insulation between outer and inner chamber for minimal thermal losses.
Caster wheel mounted for easy portability.
Front double walled door is provided with lock and key arrangement.
Door operated illumination lamp is fitted inside the chamber for easy visibility.
Finned tube evaporator facilitates uniform and faster cooling effects.
Safety Thermostate to prevent overheating.

Constructional And Salient Features

Front double walled door is provided with lock and key arrangement.
Door operated illumination lamp is fitted inside the chamber for easy visibility.
Finned tube evaporator facilitates uniform and faster cooling effects.
Safety Thermostate to prevent overheating.

Technical Specifications:

MOC Outer: Powder coated CRC Steel Sheet or Stainless Steel
MOC Inner: Chamber and trays made of Stainless Steel (SS-304)
Type: Forced Convection Type
Freezer Compressor: Hermetically sealed air cooling compressor system
Temperature Range: 5^OC to 60^OC
Accuracy: + 1 ^OC
Humidity Creation: Humidity generation (Steam Type)
Humidity Range: 5% above ambient from 40% to 95% RH at cool temperature
Humidity Accuracy: +3% RH
Controller: Microprocessor based temperature Data Logger with 9 segments to enable users to control nine different variation and repetition of temperature and humidity according to its conditions.
Electric Supply: 220/230V AC, 50/60Hz

Ordering Information with specifications:

Options:

Cat. No.	Options
LI-11201/1	Exterior illumination with fluorescent tubes
LI-11201/2	0-24 hrs cyclic timer to control cyclic illumination conditions
LI-11201/3	Communication port with interface and data cable to download data to your PC.
