Carbon Di-Oxide Incubator -129

Applications:

• With the solid double walled door, a full view inner plexi-glass door enables inspection of specimens inside the chamber without disturbing the process temperature.
• The excellent quality of magnetic gum packing for the external door.
• User-oriented design of shelves makes you adjust each space of shelves without difficulty.
• With forced air circulation at triple walled back, it maintains optimum uniformity of distribution of temperature.
• High grade Polyurethane Foam (PUF) insulation between outer and inner chamber for minimal thermal loss.
• Caster wheel mounted exterior cabinet is made of steel sheet duly powder coated.
• Inner chamber and trays are made of stainless steel sheet (SS-304 grade).
• Front double walled door is provided with lock and key arrangement.
• Door operated illumination lamp is fitted inside the chamber for easy visibility.
• Safety thermostat to prevent overheating.
• Fitted with MICROPROCESSOR BASED DIGITAL TEMPERATURE INDICATOR-CUM-CONTROLLER to control the temperature from 5°C to 60°C ±0.5°C or from Ambient to 50°C ±1°C.
• Specially designed low-cost refrigerated and non-refrigerated models are filled with integrated PLC-HMI {Compact Single Box with 7 Segment LED interface has 3 displays (3+4+4) digit + 5 keys}.
• The LOGIC Controller controls temperature within accuracy of +0.5^OC and controls the automatic times based U.V. Sterilizing Cycle through a U.V. Lamp and the gas inlet (99% CO2 or mixture of 5% CO2 rest oxygen /nitrogen) is controlled through a AUTOMATIC SOLENOID VALVE.
• CFC FREE ECO FRIENDLY COMPRESSOR.

Ordering Information with Specifications:

Options:
