Over the years of dedication, we have been a reputed supplier of Characteristics & Applications Of Basic Thyristor to our highly valued clients. It is used in scientific industry for various purposes as per the requirements. High grade raw material and machinery is used in making Characteristics & Applications Of Basic Thyristor under the vigilant eye of experts. It has gained us huge appreciation for its accuracy, quality, durability, reliability and a long service life. We offer it to our clients at pocket- friendly prices.

Objective:

To Study the Characteristics & Applications of Diac, Triac, SCR, UJT.

Technical Specifications:

• Inbuilt variable DC regulated power supplies

• Output Voltage: 0-5VDC, 0-15VDC, 0-50VDC

• On Board Analog Moving Coil Meters

• Voltmeter: 0- 20VDC, 0-2Amp / 20mA

• Ammeter: 0-200mA, 2mA/20mA

• Components provided

Resistances

Capacitors

60W Lamp with lamp holder

• High quality front panel used

• Symbol diagram printed on Front Panel & all important test Points are brought Out on front panel

• Power requirement: 230 VAC 10%, 50Hz.

• Weight: 6.0Kg Approx.

• Dimensions (mm): 455( L) x 300(B)

Standard Accessories

• Power chord, Patch chords & Instruction manual.

• Two pin main lead with one side two 4mm banana plug.

• One 60 watts lamp.

Ordering Details:
