DESCRIPTION:

Homogeneous reaction:

In an ideal CSTR (i.e. an ideal steady state flow reactor) the contents in reactor are well mixed and have uniform composition throughout. Thus the exit stream has the same composition as the fluid within the reactor. This type of reactor is known as mixed flow reactor. This set-up is used to study a non-catalytic homogeneous second order liquid phase reaction under ambient condition.

The set up consists of two feed tanks through which two reactants are fed to the reactor. Peristaltic pumps are provided to measure the individual flow of Chemicals. The flow rate can be varied by changing the speed of peristaltic pump. The CSTR is fitted with stirrer for proper mixing. From top outlet of it samples are collected for analysis.

The present set-up has a facility to interface the system with computer which enables to log the experimental data using computer. The educational software and data-logging package has been developed for unit. The software environment base is of Labview of NATIONAL INSTRUMENTS, USA. This software is compatible to interfacing unit designed by “Lab Smith”. This software package provides a comprehensive educational software environment within which the investigations can be performed. This software is capable to tabulate the sample readings according to the requirement of experiment under study and results obtained can be compared. The real time data acquisition can be done by interfacing the set-up with computer using software. Software allows the user to have control on data logging, printing the stored data, preparing spread sheets in Excel etc.

EXPERIMENTATION:

1. To study the progress of a suitable Chemical Reaction CSTR.
2. To determine the Reaction Rate Constant.

UTILITIES REQUIRED:

• Water Supply.
• Floor Drain.
• Electricity Supply: 1 Phase, 220 V AC, 0.5 kW.
• Instruments, Laboratory Glassware and Chemicals required for analysis as per the system adopted. Computer System: Pentium IV with DVD Drive, Windows XP, MS-Office XP version pre-loaded.
• One USB slot required in PC for DATA ACQUISITION CARD.

TECHNICAL DETAILS:

Control panel

comprises of

Standard make on/off switch, Mains Indicator etc.

Ordering Details:

JICRE-1001

COMPUTER CONTROLLED – CONTINUOUS STIRRED TANK REACTOR

(With Data Logging Facility)
