DESCRIPTION:

This is a dryer in which moisture removal takes place by means of forced draft action created by hot air. The set-up consists of an insulated double wall chamber. Inside the chamber a tray is attached directly to a load cell. Material for drying is placed in the tray and regular loss of weight is monitored. Air from a blower passes through a heating chamber and is used as drying agent. Arrangement is done to vary the airflow rate.

The present set-up has a facility to interface the system with computer which enables to log the experimental data using computer. The educational software and data- logging package has been developed for unit. The software environment base is of Lab view of NATIONAL INSTRUMENTS, USA. This software is compatible to interfacing unit designed by “Lab Smith”. This software package provides a comprehensive educational software environment within which the investigations can be performed. This software is capable to tabulate the sample readings according to the requirement of experiment under study and results obtained can be compared. The real time data acquisition can be done by interfacing the set-up with computer using software. Software allows the user to have control on data logging, printing the stored data, preparing spread sheets in Excel etc.

EXPERIMENTATION:

• To study the drying characteristics of a solid under forced draft condition and determine the critical moisture content.
• To correlate the constant drying rate with air mass velocity.

UTILITIES REQUIRED:

• Electricity Supply: 1 Phase, 220 V AC, 2.5 kW.
• Wet Solid.
• Floor area: 0.75 m x 2 m.
• Computer System: Pentium IV with DVD Drive, Windows 7, MS-Office pre-loaded. One USB slot
• required in PC for DATA ACQUISITION CARD.

TECHNICAL DETAILS:

Ordering Details:
