DESCRIPTION:

CRE Lab- homogeneous

In an ideal Plug Flow Reactor (PFTR) there is no mixing in the direction of flow and complete mixing perpendicular to direction of flow. Concentration of reactants varies along the length of reactor but not in radial direction. In case of a coil turbulence is introduced due to frequent change in direction of flow and presence of secondary flow, so a higher value of reaction rate constant is expected in coil tube type plug flow reactor. This set-up is used to study a non-catalytic homogeneous reaction under isothermal condition. The set up consists of two feed tanks through which two reactants are fed to the reactor. The flow rate can be varied by changing the speed of peristaltic pump. It is a helical coil tube type reactor kept in a constant temperature water bath to conduct the experiment at various temperatures. Reactants enter at lower end coming out of the top of coil from where samples are collected for analysis.

EXPERIMENTATION:

1. Sponification Reaction study in Isothermal Plug Flow Reactor.
2. To determine Reaction Rate Constant and effect of temperature on it.

UTILITIES REQUIRED:

• Water Supply
• Floor Drain.
• Electricity-1.5kw, Single.
• Instruments, Laboratory wares and Chemicals required for analysis as per the system adopted.

TECHNICAL DETAILS:

Ordering Details:

JICRE-006C

ISOTHERMAL PLUG FLOW TUBULAR REACTOR

(Coiled Tube Type) (Peristaltic Pump Feed System)
