Lab Aqua Demineralizer

Water Treatment Plant

The New “Lab Aqua Demineralizer” has several User-friendly features and are available in three standard models. De-Mineralizers/ De-ionizers (DM Plants) are based on Ion Exchange Technology and removes all the dissolved ions present in raw water and gives high purity DM water having low conductivity (<10μS/cm at 25º C), suitable for various lab applications.

Note : When the exchanger (resin) is exhausted, it has to be regenerated with diluted HCI and caustic soda for cation and anion exchanger respectively.

Ordering Information with technical specification

*: The entire unit works on low voltage. Subsidized for Education.

Additional Specifications:

• Conductivity of Demineralize water:  <10μ S/cm at 25ºC
• pH of Demineralize water: 8.5 - 9.5.
• Max Pressure: 2.5 kg/cm2.

New User-friendly features:

• Safety Feature: The entire unit works on low voltage. Hence, danger of electrical shock to the operator is eliminated
• Light indicator: The new model has light indicators that indicate the quality of Demineralize water. Green Light indicates good quality water (<30μS/cm) Red Light indicates that the unit requires regeneration owing to the high conductivity of water (>30μS/cm)
• Color Tubing: Green Tube indicates Untreated water, Blue Tube indicates Demineralize / Treated water and Red Tube indicates Effluent / waste water
• Easy to use: Regeneration procedures have been incorporated on the vessel for easy reference during regeneration and maintenance. The unit can be independently maintained by the laboratory technician.

Applications:

Demineralizer plants can be used where good quality water of low conductivity is required. In general the Demineralize water can be used for the following:

• As feed water to Distillers: For longer life of the equipment and to obtain high purity distillate, demineralised water can be used as feed water to distillers.
• In Laboratories & Research Institutes
• In Food & Diary Industries
• In Breweries & Textile Units
• In Chemical Industries
• In Pharmaceutical Industries
• In Electronic Industries
• In Storage Battery Industry & many more

Note:

•  Output is based on 250 ppm TDS
•  Raw water should be free from turbidity, free chlorine, heavy metals, organic matter, oil and should be at ambient temperature.
•  The treated water is not bacteria / pyrogen free.
•  A = Analogue model, D = Digital model (with respect to conductivity meter for Demineralizer plant).
•  Customized Demineralizer plants are also made. Suitable plants can be recommended based on the raw water analysis.
