Pre-sterilized PES Membrane Syringe Filters with pre-filter

More Views

Pre-sterilized PES Membrane Syringe Filters with pre-filter

Code:
Pre-sterilized PES Membrane Syringe Filters with pre-filter
Syringe filter type LSSYKG-S have Polyethersulfone (PES) membrane filter and a binder free Borosilicate microglassfiber prefilter in polypropylene housing.

These syringe filters are used for filtration and sterilization of difficult to filter biological fluids such as , culture media, serum and pure sera as well.
  • Absolute Retention
  • Low Protein Binding
  • High retention efficiency
  • High throughput
  • 16 Channels for minimum back pressure
  • Low extractable
  • Hydrophilic
Applications:
  • Sterile Filtration of serum solution
  • Sterile Filtration of pure sera such as Foetal Calf Serum and Foetal Bovine Serum
  • Sterile Filtration of culture media
Specifications:
Catalogue No LSSYKG-S
CONSTRUCTION
Pore size 0.2µm, 0.45µm
Prefilter Membrane Borosilicate Microglassfiber
Media Polyethersulfone (PES) Membrane
Diameter
13mm 25mm
Inlet Female luer-lock
Outlet Male luer slip
Housing Polypropylene
OPERATIONAL
Max. Operating Temperature 55 °C
Max. Differential Pressure 75 psi @ 25° C
Burst Pressure >12kg/cm2
Hold-up Volume(with air purge)
<20µl <50µl
Sterilization By Gas Sterilizable by Ethylene Oxide
Effective Filtration Area
0.8 cm² 4.15 cm²
Bubble Point (0.2 µm) > 50 psi (> 3.52 Kg/cm2)
Bubble Point (0.45 µm) > 32 psi (> 2.25 Kg/cm2)
Sample Volume
<10 ml <100 ml
Retention Efficiency (0.45µm) LRV >7 for Sr. marcescens (ATCC 14756) per cm² of filter area
Retention Efficiency (0.2µm) LRV >7 for Br. diminuta (ATCC 19146) per cm² of filter area
ASSURANCE
Fiber Release Complies with USFDA CFR Title 21, Part 210.3(b)(6) and do not requires any initial Flushing
Particle Release The filtrate Complies with USP <788> test for particulate matter in injectables
Indirect Food Additive The plastic housing material complies with the requirements of USFDA CFR Title 21 Part 177.1520
Oxidizable Substances Within limits as specified in USP
Quality Management System ISO-9001:2008 Certified
