Presterilized PES Membrane Syringe Filters

Presterilized PES Membrane Syringe Filters

More Views

Presterilized PES Membrane Syringe Filters

Code:

Presterilized PES Membrane Syringe Filters

PES membrane type LSSYPL-S have Polyethersulfone (PES) membrane filter in a poly-propylene housing. These syringe filters are used for filtration and sterilization of protein solutions, culture media and serum. The low protein binding characteristics make these ideal for these applications, particularly where sample size is very small and recovery of protein of interest is sought.

```
Absolute Retention
```
```
Low protein binding
```
```
16 Channels for minimum back pressure
```
```
High throughputs
```

Applications:

Sterilization of high value additives such as hormones, vitamins and antibiotics.

Sterilization of protein solutions, culture media and buffers

Specifications:

Catalogue No

LSSYPL-S

CONSTRUCTION

Pore size

0.2µm, 0.45µm

Media

Polyethersulfone (PES) Membrane

Diameter

4mm

13mm

25mm

Inlet

Female luer-lock

Outlet

Male luer slip

Housing

Polypropylene

OPERATIONAL

Max. Operating Temperature

55 °C

Max. Differential Pressure

75 psi @ 25° C

Burst Pressure

>12kg/cm²

Hold-up Volume(with air purge)

<5µl

<20µl

<50µl

Sterilization

Sterilizable by Ethylene Oxide

Effective Filtration Area

0.07 cm²

0.8 cm²

4.15 cm²

Bubble Point (0.2 µm)

> 50 psi (> 3.52 Kg/cm²)

Bubble Point (0.45 µm)

> 32 psi

Clean Water Flow Rate @ 20 psi (0.2µm)

> 0.8 ml/min

> 12 ml/min

> 80 ml/min

Clean Water Flow Rate @ 20 psi (0.45µm)

> 4 ml/min

> 30 ml/min

> 180 ml/min

Sample Volume

<1ml

<10ml

<100ml

Retention Efficiency (0.45µm)

LRV >7 for Sr. marcescens (ATCC 14756) per cm² of filter area

Retention Efficiency (0.2µm)

LRV >7 for Br. diminuta (ATCC 19146) per cm² of filter area

ASSURANCE

Fiber Release

Complies with USFDA CFR Title 21, Part 210.3(b)(6) and do not requires any initial Flushing.

Particle Release

The filtrate Complies with USP <788> test for particulate matter in injectables.

Indirect Food Additive

The plastic housing material complies with the requirements of USFDA CFR Title 21 Part 177.1520.

Extractables with WFI

Passes test as per USP

Quality Management System

ISO-9001:2008 Certified

Description

Details

Presterilized PES Membrane Syringe Filters

PES membrane type LSSYPL-S have Polyethersulfone (PES) membrane filter in a poly-propylene housing. These syringe filters are used for filtration and sterilization of protein solutions, culture media and serum. The low protein binding characteristics make these ideal for these applications, particularly where sample size is very small and recovery of protein of interest is sought.

```
Absolute Retention
```
```
Low protein binding
```
```
16 Channels for minimum back pressure
```
```
High throughputs
```

Applications:

Sterilization of high value additives such as hormones, vitamins and antibiotics.

Sterilization of protein solutions, culture media and buffers

Specifications:

Catalogue No

LSSYPL-S

CONSTRUCTION

Pore size

0.2µm, 0.45µm

Media

Polyethersulfone (PES) Membrane

Diameter

4mm

13mm

25mm

Inlet

Female luer-lock

Outlet

Male luer slip

Housing

Polypropylene

OPERATIONAL

Max. Operating Temperature

55 °C

Max. Differential Pressure

75 psi @ 25° C

Burst Pressure

>12kg/cm²

Hold-up Volume(with air purge)

<5µl

<20µl

<50µl

Sterilization

Sterilizable by Ethylene Oxide

Effective Filtration Area

0.07 cm²

0.8 cm²

4.15 cm²

Bubble Point (0.2 µm)

> 50 psi (> 3.52 Kg/cm²)

Bubble Point (0.45 µm)

> 32 psi

Clean Water Flow Rate @ 20 psi (0.2µm)

> 0.8 ml/min

> 12 ml/min

> 80 ml/min

Clean Water Flow Rate @ 20 psi (0.45µm)

> 4 ml/min

> 30 ml/min

> 180 ml/min

Sample Volume

<1ml

<10ml

<100ml

Retention Efficiency (0.45µm)

LRV >7 for Sr. marcescens (ATCC 14756) per cm² of filter area

Retention Efficiency (0.2µm)

LRV >7 for Br. diminuta (ATCC 19146) per cm² of filter area

ASSURANCE

Fiber Release

Complies with USFDA CFR Title 21, Part 210.3(b)(6) and do not requires any initial Flushing.

Particle Release

The filtrate Complies with USP <788> test for particulate matter in injectables.

Indirect Food Additive

The plastic housing material complies with the requirements of USFDA CFR Title 21 Part 177.1520.

Extractables with WFI

Passes test as per USP

Quality Management System

ISO-9001:2008 Certified
