Installation Of Germination Chamber With Air Cooler, Time Controller, Light, Electricity, Temperature, & Humidity Controller & Stainless Steel Rack

Special Features:

• The Walk-in Growth Chamber is advanced CFC FREE refrigeration system. Prevents chamber icing and condensation. Ideal for artificial light source plant growth test lab, walk-in chamber inside.
• Programmable microprocessor digital PID control ensures high level accuracy.
• Preheating technology by humidified evaporator eliminates hot and cold spots.
• 6-point digital recorder and growth shelf.

Specifications :

• Capacity : 5,040 liters
• Chamber (WxBxH) : 2000 x 1400 x 1800mm (Approx.), ( 2m x 1.4m x 1.8m )
• Stainless Steel Rack : 9 Nos.,
• Rack Size : 20” x 18” x 70”, W x D x H. ( Approx), Per Rack 5 Nos. Wire Mesh Shelf.
• Temperature range : 10 to 40°C
• Accuracy : ±0.2°C/Uniformity: ±1°C at 20°C
• Humidity range : 35 to 95% RH, Accuracy ±1.0%
• Uniformity : 5% at 60% RH
• Illumination Range : 0-50,000 Lux
• CO2 range : 0 – 5000 ppm
• Lamp : 14 x HPS 420W
• Refrigerator : 1 x 4 HP
• Timer : 24 hours
• Control &display : Microprocessor PID controller with digital LED display.
• Safety device : Over temperature protector(Thermostat ), safety cut-off valve, over current.
• Material Interior : Stainless steel 304 plate Exterior Powder coated Pre-Coated GI steel plate.
• Power source : 220-240VAC, 50Hz, single phase Preparation of room, air conditioner, time controller, light, electricity, temperature and humidity controller and stainless steel rack included.
