3500 Self Combine Harvester

3500 Self Combine Harvester

More Views

3500 Self Combine Harvester

Code:
3500 Self Combine Harvester

Specification:
Engine
TYPE Ashok Leyland
ALU04WD/16
No. of Cylinders 4(Four)
BHP Maximum 76 PS 2200 RPM
Cooling System Water Cooled
Cutter Bar
Width 2970mm to 3124 mm
Height Adjustment Hydraulically
Cutting Height Min 100 mm
Cutting Height Max 500mm
Reel
TYPE: Pick Up
Speed Adjustment Mechanically
Height Adjustment Hydraulically
Thresher Drum
Dia. of Drum 600 mm
Length of Drum 890 mm
Speed of Drum 535 to 1210 rpm
Adjustment Mechanically
No. of Rasp Bars 8(Eight)
No. of Spikes 88
Concave
Clearance Between 16 to 39 mm
Concave & Thresher 3 to 16 mm
Mechanically
No. of Spikes 25
Straw Walkers
No. of Straw Walkers 4(Four)
Total Area 26232 sq. cm.
Cleaning
Area 16422 sq. cm.
Adjustment Mechanically
Ground Speed
1st Gear Km/h 1.5 to 3.5
2nd Gear Km/h 3.5 to 9.0
3rd Gear Km/h 8.5 to 21.9
Reverse Gear Km/h 3.5 to 9.0
Fan
No. of Blades 6(Six)
Diameter of Fan 455 mm
Width of Fan 880 mm
Adjustment Mechanically
Steering
Steering System Hydraulic
Capacity
Fuel tank  125 Ltrs.
1.9 meter
Grain Tank Cube
Hyd. Oil Tank 25 Ltrs.
Tyre Size
Front 16-09-28
Rear/Trolley 7.50/16
Dimensions
Length 7315 mm
Width 3050 mm
Height 3353 mm
Min Ground Clearance 500 mm
Weight 6095 Kgs. (Approx.)
Working Capacity
Wheat 1.5-2.5 Acres/hour approx.
Paddy 1.0-2.0 Acres/hour

Ordering Details:
Catalogue No. Description
JSCH-3500 3500 Self Combine Harvester

Description

Details

3500 Self Combine Harvester

Specification:
Engine
TYPE Ashok Leyland
ALU04WD/16
No. of Cylinders 4(Four)
BHP Maximum 76 PS 2200 RPM
Cooling System Water Cooled
Cutter Bar
Width 2970mm to 3124 mm
Height Adjustment Hydraulically
Cutting Height Min 100 mm
Cutting Height Max 500mm
Reel
TYPE: Pick Up
Speed Adjustment Mechanically
Height Adjustment Hydraulically
Thresher Drum
Dia. of Drum 600 mm
Length of Drum 890 mm
Speed of Drum 535 to 1210 rpm
Adjustment Mechanically
No. of Rasp Bars 8(Eight)
No. of Spikes 88
Concave
Clearance Between 16 to 39 mm
Concave & Thresher 3 to 16 mm
Mechanically
No. of Spikes 25
Straw Walkers
No. of Straw Walkers 4(Four)
Total Area 26232 sq. cm.
Cleaning
Area 16422 sq. cm.
Adjustment Mechanically
Ground Speed
1st Gear Km/h 1.5 to 3.5
2nd Gear Km/h 3.5 to 9.0
3rd Gear Km/h 8.5 to 21.9
Reverse Gear Km/h 3.5 to 9.0
Fan
No. of Blades 6(Six)
Diameter of Fan 455 mm
Width of Fan 880 mm
Adjustment Mechanically
Steering
Steering System Hydraulic
Capacity
Fuel tank  125 Ltrs.
1.9 meter
Grain Tank Cube
Hyd. Oil Tank 25 Ltrs.
Tyre Size
Front 16-09-28
Rear/Trolley 7.50/16
Dimensions
Length 7315 mm
Width 3050 mm
Height 3353 mm
Min Ground Clearance 500 mm
Weight 6095 Kgs. (Approx.)
Working Capacity
Wheat 1.5-2.5 Acres/hour approx.
Paddy 1.0-2.0 Acres/hour

Ordering Details:
Catalogue No. Description
JSCH-3500 3500 Self Combine Harvester
