A.C Combine Harvester

A.C Combine Harvester

More Views

A.C Combine Harvester

Code:
A.C Combine Harvester

Specifications:
ENGINE
TYPE Ashok Leyland
H6ET1C3RD22/1 101 H.P @2200 RPM
No. of Cylinders 6(SIX)
Cooling System Water Cooled
CUTTER BAR
Width 4199 mm
Height Adjustment Hydraulically
Cutting Height Min 100 mm
Cutting Height Max 700 mm
REEL
TYPE Pick Up
Speed Adjustment Mechanically
Height Adjustment Hydraulically
Thresher Drum
Dia of Drum 600 mm
Length of Drum 1270 mm
Speed of Drum 535 to 1210 rpm
Adjustment Mechanically
No. of Rasp Bars 8(Eight)
No. of Spikes 128
Concave
Clearance Between 16 to 39 mm
Concave & Thresher 3 to 16 mm
No. of Spikes
  • Mechanically
  • 36
Straw Walkers
No. of Straw Walkers 5(FIVE)
Total Area 46565 sq. cm.
Cleaning
Area 16422 sq. cm.
Adjustment Mechanically
Ground Speed
1st Gear Km/h 1.5 to 3.5
2nd Gear Km/h 3.5 to 9.0
3rd Gear Km/h 8.5 to 21.9
Reverse Gear Km/h 3.5 to 9.0
Fan
No. of Blades 5(FIVE)
Diameter of Fan 600 mm
Width of Fan 1260 mm
Adjustment Mechanically
Steering
Steering System Hydraulic
Capacity
Fuel tank 380 Lts.
Grain Tank 2.64 meter Cube
Hyd. Oil Tank 25 Lts.
Tyre Size
Front 18.4/15/30
Rear/Trolley 9.00 X 16
Dimensions
Length 8535 mm
Height 4572 mm
Min Ground Clearance 460 mm
Weight 9150 Kgs. (Approx.)
Working Capacity
Wheat 4.5 Acres/hour approx.
Paddy 4 Acres/hour approx.

Ordering Details:
Catalogue No. Description
JACH-01 A.C Combine Harvester

Description

Details

A.C Combine Harvester

Specifications:
ENGINE
TYPE Ashok Leyland
H6ET1C3RD22/1 101 H.P @2200 RPM
No. of Cylinders 6(SIX)
Cooling System Water Cooled
CUTTER BAR
Width 4199 mm
Height Adjustment Hydraulically
Cutting Height Min 100 mm
Cutting Height Max 700 mm
REEL
TYPE Pick Up
Speed Adjustment Mechanically
Height Adjustment Hydraulically
Thresher Drum
Dia of Drum 600 mm
Length of Drum 1270 mm
Speed of Drum 535 to 1210 rpm
Adjustment Mechanically
No. of Rasp Bars 8(Eight)
No. of Spikes 128
Concave
Clearance Between 16 to 39 mm
Concave & Thresher 3 to 16 mm
No. of Spikes
  • Mechanically
  • 36
Straw Walkers
No. of Straw Walkers 5(FIVE)
Total Area 46565 sq. cm.
Cleaning
Area 16422 sq. cm.
Adjustment Mechanically
Ground Speed
1st Gear Km/h 1.5 to 3.5
2nd Gear Km/h 3.5 to 9.0
3rd Gear Km/h 8.5 to 21.9
Reverse Gear Km/h 3.5 to 9.0
Fan
No. of Blades 5(FIVE)
Diameter of Fan 600 mm
Width of Fan 1260 mm
Adjustment Mechanically
Steering
Steering System Hydraulic
Capacity
Fuel tank 380 Lts.
Grain Tank 2.64 meter Cube
Hyd. Oil Tank 25 Lts.
Tyre Size
Front 18.4/15/30
Rear/Trolley 9.00 X 16
Dimensions
Length 8535 mm
Height 4572 mm
Min Ground Clearance 460 mm
Weight 9150 Kgs. (Approx.)
Working Capacity
Wheat 4.5 Acres/hour approx.
Paddy 4 Acres/hour approx.

Ordering Details:
Catalogue No. Description
JACH-01 A.C Combine Harvester
