Round Baler

Round Baler

More Views

Round Baler

Code:
Round Baler

Description
Crop residues like Paddy/wheat straw, sugarcane trash left in the field after harvesting, have immense commercial value as cattle fodder, biomass power generation, ethanol production, paper production, packaging material, mushroom cultivation, practical board manufacturing, organic manure and many more.

Technical Specifications & Ordering Details:
Model JSRB-60
Dimensions & Weighs
Overall  LxWxH (mm/inch) 2350x1780x1515/92.52x70.08x59.65
Ground Clearance (Axle Height) mm/inch 337/13.27
Tyre Size
Axle Tyre Size 5.2-14, 8 ply
Pick Up Tyre Size 4-8, 6 ply
Tractor Requirement
Horse Power (Hp/Kw) & PTO Speed (rpm) 25/19 mm(min) & 540
Hitching System Draw bar Hitch
Bale chamber Chain driven Pressure roller rotating on sealed bearing at ends
Type No. of Roller 19
Roller Dia X length (mm/inch) 93x622/ 3.66x24.49
Roller Chamber Dia X Width (mm/inch) 595x633/ 23.43x24.92
Bale Size
Bale Dia. X width (mm/inch) 600x635 / 23.62x25
Working Capacity (Bales/ Hr) 50*
Bale Weight (kg/lbs) 17 to 20**/37 to 44**
Pick Up System
Type Fully Floating, Cylindrical drum With Spring tines
Tine Bar 4
No Of Tines 40
Binding (Twine) System
Binding Activation Manual
Twine Recommended Sisal Or Polypropylene


Advantages
BENEFITS OF JSRB-60 BALER
Simple compact machine
  • Suitable for small and medium farmers
  • Easy to operate
  • Less Maintenance
  • Can operate in small paddy fields
Less Power requirement
  • Lower HP tractor (25 hp)  is sufficient
  • Less fuel consumption
  • Low operating cost
Compact round bales
  • 2 feet diameter and 2 feet width
  • 15 to 25* kg weight bales
  • Easy to handle & transport
Description

Details

Round Baler

Description
Crop residues like Paddy/wheat straw, sugarcane trash left in the field after harvesting, have immense commercial value as cattle fodder, biomass power generation, ethanol production, paper production, packaging material, mushroom cultivation, practical board manufacturing, organic manure and many more.

Technical Specifications & Ordering Details:
Model JSRB-60
Dimensions & Weighs
Overall  LxWxH (mm/inch) 2350x1780x1515/92.52x70.08x59.65
Ground Clearance (Axle Height) mm/inch 337/13.27
Tyre Size
Axle Tyre Size 5.2-14, 8 ply
Pick Up Tyre Size 4-8, 6 ply
Tractor Requirement
Horse Power (Hp/Kw) & PTO Speed (rpm) 25/19 mm(min) & 540
Hitching System Draw bar Hitch
Bale chamber Chain driven Pressure roller rotating on sealed bearing at ends
Type No. of Roller 19
Roller Dia X length (mm/inch) 93x622/ 3.66x24.49
Roller Chamber Dia X Width (mm/inch) 595x633/ 23.43x24.92
Bale Size
Bale Dia. X width (mm/inch) 600x635 / 23.62x25
Working Capacity (Bales/ Hr) 50*
Bale Weight (kg/lbs) 17 to 20**/37 to 44**
Pick Up System
Type Fully Floating, Cylindrical drum With Spring tines
Tine Bar 4
No Of Tines 40
Binding (Twine) System
Binding Activation Manual
Twine Recommended Sisal Or Polypropylene


Advantages
BENEFITS OF JSRB-60 BALER
Simple compact machine
  • Suitable for small and medium farmers
  • Easy to operate
  • Less Maintenance
  • Can operate in small paddy fields
Less Power requirement
  • Lower HP tractor (25 hp)  is sufficient
  • Less fuel consumption
  • Low operating cost
Compact round bales
  • 2 feet diameter and 2 feet width
  • 15 to 25* kg weight bales
  • Easy to handle & transport
