Self Propelled Platform

Code:
Self Propelled Platform

Description
Dawn of a New Era
  • It increases productivity compared to traditional climbing.
  • Operator can pluck the fruits and store them in bucket thus avoiding damage to fruits from falling down.
  • Spraying becomes more easy and effective by spraying from top of the tree.
  • Power operated tools replace traditional tools for easy and faster pruning and lopping. The equipment can also be used for allied works such as maintenance works on street lights, white washing and painting of buildings within the operating height
Technical Specifications & Ordering Details:
Model JSSP-800
Machine Weight (kg/lbs) 2025/4455
Working Height (mm/inch) 8000/314
Platform size (mm/ inch0 510x510x950/ 20.08x20.08x37.4
Platform Load (kg/lbs) 145/ 319
Overall Length (mm/ inch) 7900 /311
Overall width (mm/ inch) 2550/ 100.04
Platform capacity Single Operator
Max. Hydraulic System Pressure 150 Bar
Max. Hydraulic System Flow 20 ltr.
Fuel  Tank 16 ltr Approx.
Hydraulic oil tank capacity 20 ltr.
Engine 14 HP water cooled diesel engine
Model STMP-26

Description

Details

Self Propelled Platform

Description
Dawn of a New Era
  • It increases productivity compared to traditional climbing.
  • Operator can pluck the fruits and store them in bucket thus avoiding damage to fruits from falling down.
  • Spraying becomes more easy and effective by spraying from top of the tree.
  • Power operated tools replace traditional tools for easy and faster pruning and lopping. The equipment can also be used for allied works such as maintenance works on street lights, white washing and painting of buildings within the operating height
Technical Specifications & Ordering Details:
Model JSSP-800
Machine Weight (kg/lbs) 2025/4455
Working Height (mm/inch) 8000/314
Platform size (mm/ inch0 510x510x950/ 20.08x20.08x37.4
Platform Load (kg/lbs) 145/ 319
Overall Length (mm/ inch) 7900 /311
Overall width (mm/ inch) 2550/ 100.04
Platform capacity Single Operator
Max. Hydraulic System Pressure 150 Bar
Max. Hydraulic System Flow 20 ltr.
Fuel  Tank 16 ltr Approx.
Hydraulic oil tank capacity 20 ltr.
Engine 14 HP water cooled diesel engine
Model STMP-26
