Galvanised Steel Pipes & Black Steel Pipes

Galvanised Steel Pipes & Black Steel Pipes

More Views

Galvanised Steel Pipes & Black Steel Pipes

Code:
Galvanised Steel Pipes & Black Steel Pipes
For Ordinary Uses in Water, Gas, Air and Steam
 Conforming To IS:1239 (PtI)-1990
 Equivalent to BS - 1387/1985

 		 Outside Diameter Wall thickness Nominal Mass of Steel Tubes Socket
Plain end Screwed & Socketed
N.B. MM. & Series INCH.  Minimum  MM   Maximum  MM   MM   SWG  KG/Mtrs. Mtrs per tonne Kg/Mtrs Mtrs per tonne No. of pipes approx. tonne bundle Minimum Outer diameter MM Minimum Length MM
15 L 1/2 21.0 21.4 2.00 14 0.947 1056 0.956 1046 165
M 1/2 21.0 21.8 2.60 12 1.210 826 1.220 820 132 27.0 37.0
H 1/2 21.0 21.8 3.20 10 1.440 694 1.450 690 110
20 L 3/4 26.4 26.9 2.30 13 1.380 725 1.390 719 112
M 3/4 26.5 27.3 2.60 12 1.560 641 1.570 637 98 32.5 39.0
H 3/4 26.5 27.3 3.20 10 1.870 535 1.880 532 84
25 L 1 33.2 33.8 2.60 12 1.980 505 2.000 500 80
M 1 33.3 34.2 3.20 10 2.410 415 2.430 412 65 39.5 46.0
H 1 33.3 34.2 4.00 8 2.930 341 2.950 339 55
32 L 1 1/4 41.9 42.5 2.60 12 2.540 394 2.570 389 60
M 1 1/4 42.0 42.9 3.20 10 3.100 323 3.130 319 51 49.5 51.0
H 1 1/4 42.0 42.9 4.00 8 3.790 264 3.820 262 42
40 L 1 1/2 47.8 48.4 2.90 11 3.230 310 3.270 306 48
M 1 1/2 47.9 48.8 3.20 10 3.560 281 3.600 278 45 56.0 51.0
H 1 1/2 47.9 48.8 4.00 8 4.370 229 4.410 227 36
50 L 2 59.6 60.2 2.90 11 4.080 245 4.150 241 39
M 2 59.7 60.8 3.60 9 3.030 199 5.100 196 30 68.0 60.0
H 2 59.7 60.8 4.50 7 6.190 162 6.260 160 27
65 L 2 1/2 75.2 76.0 3.20 10 5.710 175 5.830 172 27
M 2 1/2 75.3 76.6 3.60 9 6.420 156 6.540 153 24 84.0 69.0
H 2 1/2 75.3 76.6 4.50 7 7.930 126 8.050 124 20
80 L 3 87.9 88.7 3.20 10 6.720 149 6.890 145 23
M 3 88.0 89.5 4.00 8 8.360 120 8.530 117 19 98.0 75.0
H 3 88.0 89.5 4.80 6 9.900 101 10.100 96 16
100 L 4 113.0 113.9 3.60 9 9.750 103 10.000 100 16
M 4 113.1 115.0 4.50 7 12.200 82 12.500 80 13 124.0 87.0
H 4 113.1 115.0 5.40 5 14.500 69 14.800 68 11
125 M 5 138.5 140.8 4.80 6 15.900 63 16.400 61 10
H 5 138.5 140.8 5.40 5 17.900 56 18.400 54 9 151.0 96.0
150 M 6 163.9 166.5 4.80 6 18.900 53 19.500 51 8
H 6 163.9 166.5 5.40 5 21.300 47 21.900 46 7 178.0 96.0

ORDERING DETAILS:
Catalogue No Description
JSP-2150 Galvanised Steel Pipes & Black Steel Pipes

Description

Details

Galvanised Steel Pipes & Black Steel Pipes
For Ordinary Uses in Water, Gas, Air and Steam
 Conforming To IS:1239 (PtI)-1990
 Equivalent to BS - 1387/1985

 		 Outside Diameter Wall thickness Nominal Mass of Steel Tubes Socket
Plain end Screwed & Socketed
N.B. MM. & Series INCH.  Minimum  MM   Maximum  MM   MM   SWG  KG/Mtrs. Mtrs per tonne Kg/Mtrs Mtrs per tonne No. of pipes approx. tonne bundle Minimum Outer diameter MM Minimum Length MM
15 L 1/2 21.0 21.4 2.00 14 0.947 1056 0.956 1046 165
M 1/2 21.0 21.8 2.60 12 1.210 826 1.220 820 132 27.0 37.0
H 1/2 21.0 21.8 3.20 10 1.440 694 1.450 690 110
20 L 3/4 26.4 26.9 2.30 13 1.380 725 1.390 719 112
M 3/4 26.5 27.3 2.60 12 1.560 641 1.570 637 98 32.5 39.0
H 3/4 26.5 27.3 3.20 10 1.870 535 1.880 532 84
25 L 1 33.2 33.8 2.60 12 1.980 505 2.000 500 80
M 1 33.3 34.2 3.20 10 2.410 415 2.430 412 65 39.5 46.0
H 1 33.3 34.2 4.00 8 2.930 341 2.950 339 55
32 L 1 1/4 41.9 42.5 2.60 12 2.540 394 2.570 389 60
M 1 1/4 42.0 42.9 3.20 10 3.100 323 3.130 319 51 49.5 51.0
H 1 1/4 42.0 42.9 4.00 8 3.790 264 3.820 262 42
40 L 1 1/2 47.8 48.4 2.90 11 3.230 310 3.270 306 48
M 1 1/2 47.9 48.8 3.20 10 3.560 281 3.600 278 45 56.0 51.0
H 1 1/2 47.9 48.8 4.00 8 4.370 229 4.410 227 36
50 L 2 59.6 60.2 2.90 11 4.080 245 4.150 241 39
M 2 59.7 60.8 3.60 9 3.030 199 5.100 196 30 68.0 60.0
H 2 59.7 60.8 4.50 7 6.190 162 6.260 160 27
65 L 2 1/2 75.2 76.0 3.20 10 5.710 175 5.830 172 27
M 2 1/2 75.3 76.6 3.60 9 6.420 156 6.540 153 24 84.0 69.0
H 2 1/2 75.3 76.6 4.50 7 7.930 126 8.050 124 20
80 L 3 87.9 88.7 3.20 10 6.720 149 6.890 145 23
M 3 88.0 89.5 4.00 8 8.360 120 8.530 117 19 98.0 75.0
H 3 88.0 89.5 4.80 6 9.900 101 10.100 96 16
100 L 4 113.0 113.9 3.60 9 9.750 103 10.000 100 16
M 4 113.1 115.0 4.50 7 12.200 82 12.500 80 13 124.0 87.0
H 4 113.1 115.0 5.40 5 14.500 69 14.800 68 11
125 M 5 138.5 140.8 4.80 6 15.900 63 16.400 61 10
H 5 138.5 140.8 5.40 5 17.900 56 18.400 54 9 151.0 96.0
150 M 6 163.9 166.5 4.80 6 18.900 53 19.500 51 8
H 6 163.9 166.5 5.40 5 21.300 47 21.900 46 7 178.0 96.0

ORDERING DETAILS:
Catalogue No Description
JSP-2150 Galvanised Steel Pipes & Black Steel Pipes
