SOCKETED CASING PIPES

More Views

SOCKETED CASING PIPES

Code:

SOCKETED CASING PIPES

All dimensions are in millimetres

Nominal Bore of Pipe	Outside Diameter of Pipe	Thickness of Pipe	Mass of Plain Tube	Socket Outside Diameter	Overall length of Socket, min
100	114.3	5.4	14.5	130.0	114.3
125	141.3	5.4	18.1	157.0	120.6
		7.1	23.5
150	168.3	5.4	21.6	154.0	127.0
		7.1	28.2
175	193.7	6.4	29.6	211.6	152.4
		8.0	36.6
200	219.1	6.4	33.6	237.0	152.4
		8.0	41.6
225	244.5	7.1	41.6	262.5	165.1
		9.0	52.3
250	273.1	8.0	52.3	291.0	177.8
		10.0	64.9
300	323.9	8.0	62.3	346.0	177.8
		10.0	77.4


The values have been calculated on the basis of the formula:
W=0.024 66 x (D-t) t kg/metre. Where D = outside diameter in mm, and T= thickness in mm.

ORDERING DETAILS:

Catalogue No	Description
JSP-2350	SOCKETED CASING PIPES
