ALTERNATOR (A.C. / DC GENERATORS)

ALTERNATOR TO RUN BY TRACTOR PTO SHAFT

• A.C GENERATORS specially designed, self-excited, self regulated, screen protected, drip-proof enclosure, 1500 /1800 RPM manufactured as per IS:13364 part 1 & 2 under strict quality control.

• Specially designed heavy duty with temp. rise, better air circulation & greater efficiency.

• Also available in SEMI- Brushless & brushless in particular range.

SINGLE PHASE, Two wire 230/240 VOLTS, 50/60 CYCLE

KVA

KW

P.F

Prime Mover Engine/

Tractor RPM

THREE PHASE, Four Wire 380-440 VOLTS, 50/60 CYCLE

KVA

KW

P.F

Prime Mover Engine/

Tractor RPM

ON SPECIAL REQUEST WE CAN SUPPLY ALTERNATORS UPTO1000 KVA

OPTIONALS:

INDUCTIVE ALTERNATORS are specially designed for extra heavy duty. These alternators come with built in “C” transformer and modern electronic circuit to prevent diode failure. In this series these there is power saving and consistent voltage. Inductive models are suitable for high torque loads like compressors and motors.

AVR ALTERNATORS
Automatic voltage control, The voltage control unit (AVR) is a solid state, encapsulated, state of art design with latest technology.

WELDING CURRENT ALTERNATORS  Are designed to direct welding with adequate current regulator & provision for domestic light supply.

TRACTOR PTO SHAFT DRIVEN AC ALTERNATORS
We can also supply special arrangement in alternator so that it can be driven by Tractor PTO shaft.

NEW AGROWAVE DC ALTERNATOR

SPECIFICATIONS

• DC output 12 volts, 200 Amps.

• DC Voltage regulated at 1 Volt from no-load to full load.

• Dc Voltage will reduce drastically after the load current reaches its rated current & hence protecting generator & Engine from over load.

• Separately Excited, Brushless, Provided with class 'H' Insulation, Temp. rise limited to Class F. Suitable for an ambient temperature of 40C.

• D.C. Alternator for recharging battery banks. This is not an automotive style alternator because of their poor efficiency.

• 200 amps DC for recharging battery banks, DC generator is the most efficient and least cost solution.

• Require 5 h.p Prime mover at 1500 RPM ENGINE suitable to make a DC generator.
