Diesel Generators Three Phase

Diesel Generators Three Phase

More Views

Diesel Generators Three Phase

Code:
Diesel Generators Three Phase
ENGINE
Cooling Water /Air
No. of Cyl. One / Two
Fuel H.S. Diesel
Speed 1500 RPM
SFC 1 gms/HP-Hr

A. C. GENERATOR
Voltage 230/415 V
Phase Single/Three
Frequency 50 Hz
Regulation ± 5 % Max.
Insulation F Class
Mounting Foot

MODEL KVA  KW BHP  RPM  No. Of Piston  Cooling  Packing Size (cm)  Nett. Wt. Kg.  Gross Wt. Kg.
THREE PHASE 415 Volts 4 pole 50 Hz
V-11 6.25 5 8 1500 SINGLE Water/Air 112x65x130 340 490
V-12 7.5 6 10 1500 SINGLE Water/Air 112x65x130 365 515
V-13 8.75 7 11 1500 SINGLE Water/Air 112x65x135 380 530
V-14 10 8 14 1500 SINGLE Water 120x70x160 400 550
V-15 10 8 15 1500 DOUBLE Water/Air 120x70x160 450 640
V-16 12.5 10 15 1500 DOUBLE Water/Air 120x70x160 456 645
V-17 15 12 20 1500 DOUBLE Water/Air 120x70x160 485 670
V-18 17.5 14 22 1500 DOUBLE Water/Air 120x70x160 495 690
V-19 20 16 28 1500 DOUBLE Water 125x85x165 510 710
V-19H 22 18 30 1500 DOUBLE Water 125x85x165 130 740


SPECIFICATIONS

GOVERNING
A sensible mechanical centrifugal type governor mounted on the camshaft gear. Speed variation is controlled within limits to comply with class B1 governing as per IS:10001 (GENERAL PURPOSE).

COOLING
Engine is continuously cooled by flow of water. Either by Radiator mounted on engine or direct water supply. Front radiator mounted engines also available.

STARTING
The engine is designed for starting by hand. Electric Start Provision can also be provided against specific requirement. Dynamo battery chargers also available.

POLLUTION CONTROL DEVICE
Single Element Catalytic Converter for control of NOx, CO, THC & HAPs.

SOUND & VIBRATION CONTROL DEVICE
We offer Canopy, Industrial type Air cleaner & Silencer, Round Duct Expansion Joints, Anti Vibration Mounts etc.

ENGINE SAFTY DEVICE (OPTIONAL)
Engine controller with Manual Start/ Stop, Automatic shut down for fault, Keyswitch operation, 16A contacts for start/stop, Electronic warning lamp.

ENGINE SAFTY DEVICE CONTROLLER (OPTIONAL)
Display of Battery Voltage, Oil Pressure, Temperature, Engine RPM & Running Hrs. , 14 Programmable parameters, Electronic alternator excitation circuit, 5 Digital & 4 Analog inputs, 3 relay outputs for start, Stop and one is programmable, Engine run hours counter, Automatic & manual operation mode, Remote Start & stop function. Sound Proofing canopy can also supplied.

DIESEL WATER COOLED GENSET
ENGINE
Cooling Water Cooled
Fuel H.S. Diesel
Speed 1500 RPM
Type Vertical ,4-stroke,compression ignition
Injection Direct by multi-hole nozzel
RPM 1500-1800
Starting Electrical (12 Volts)
Governor Mechanical

A. C. GENERATOR
Voltage 230/415 V
Phase Single/Three
Frequency 50 Hz
Insulation F Class
Power Factor 0.8



 AC GENERATORS







DIESEL ENGINE


MODEL RATED OUTPUT CURRENT (AMPS) RATED POWER (HP) NO. OF CYLIN- DERS SWEPT VOLUME (CC) SPECIFIC FUEL CONSUMP- TION (GM/ BHP-HR) ASPIRA- TION
KVA KW THREE PHASE
JVMG-25 25 20 35 32 2 2376 162 Natural
JVMG-30 30 24 42 41 3 3307 162 Natural
JVMG-35 35 28 49 46* 3 3307 162 Natural
JVMG-40 40 32 56 56 4 4561 159 Natural
JVMG-45 45 36 63 56 4 4561 159 Natural
JVMG-50 50 40 70 62* 4 4561 169 Natural
JVMG-65 65 52 90 84 4 4561 162 Turbo Charged
JVMG-82 82.5 66 114 106 6 6614 152 Turbo Charged
JVMG-100 100 80 138 125 6 6614 152 Turbo Charged
Description

Details

Diesel Generators Three Phase
ENGINE
Cooling Water /Air
No. of Cyl. One / Two
Fuel H.S. Diesel
Speed 1500 RPM
SFC 1 gms/HP-Hr

A. C. GENERATOR
Voltage 230/415 V
Phase Single/Three
Frequency 50 Hz
Regulation ± 5 % Max.
Insulation F Class
Mounting Foot

MODEL KVA  KW BHP  RPM  No. Of Piston  Cooling  Packing Size (cm)  Nett. Wt. Kg.  Gross Wt. Kg.
THREE PHASE 415 Volts 4 pole 50 Hz
V-11 6.25 5 8 1500 SINGLE Water/Air 112x65x130 340 490
V-12 7.5 6 10 1500 SINGLE Water/Air 112x65x130 365 515
V-13 8.75 7 11 1500 SINGLE Water/Air 112x65x135 380 530
V-14 10 8 14 1500 SINGLE Water 120x70x160 400 550
V-15 10 8 15 1500 DOUBLE Water/Air 120x70x160 450 640
V-16 12.5 10 15 1500 DOUBLE Water/Air 120x70x160 456 645
V-17 15 12 20 1500 DOUBLE Water/Air 120x70x160 485 670
V-18 17.5 14 22 1500 DOUBLE Water/Air 120x70x160 495 690
V-19 20 16 28 1500 DOUBLE Water 125x85x165 510 710
V-19H 22 18 30 1500 DOUBLE Water 125x85x165 130 740


SPECIFICATIONS

GOVERNING
A sensible mechanical centrifugal type governor mounted on the camshaft gear. Speed variation is controlled within limits to comply with class B1 governing as per IS:10001 (GENERAL PURPOSE).

COOLING
Engine is continuously cooled by flow of water. Either by Radiator mounted on engine or direct water supply. Front radiator mounted engines also available.

STARTING
The engine is designed for starting by hand. Electric Start Provision can also be provided against specific requirement. Dynamo battery chargers also available.

POLLUTION CONTROL DEVICE
Single Element Catalytic Converter for control of NOx, CO, THC & HAPs.

SOUND & VIBRATION CONTROL DEVICE
We offer Canopy, Industrial type Air cleaner & Silencer, Round Duct Expansion Joints, Anti Vibration Mounts etc.

ENGINE SAFTY DEVICE (OPTIONAL)
Engine controller with Manual Start/ Stop, Automatic shut down for fault, Keyswitch operation, 16A contacts for start/stop, Electronic warning lamp.

ENGINE SAFTY DEVICE CONTROLLER (OPTIONAL)
Display of Battery Voltage, Oil Pressure, Temperature, Engine RPM & Running Hrs. , 14 Programmable parameters, Electronic alternator excitation circuit, 5 Digital & 4 Analog inputs, 3 relay outputs for start, Stop and one is programmable, Engine run hours counter, Automatic & manual operation mode, Remote Start & stop function. Sound Proofing canopy can also supplied.

DIESEL WATER COOLED GENSET
ENGINE
Cooling Water Cooled
Fuel H.S. Diesel
Speed 1500 RPM
Type Vertical ,4-stroke,compression ignition
Injection Direct by multi-hole nozzel
RPM 1500-1800
Starting Electrical (12 Volts)
Governor Mechanical

A. C. GENERATOR
Voltage 230/415 V
Phase Single/Three
Frequency 50 Hz
Insulation F Class
Power Factor 0.8



 AC GENERATORS







DIESEL ENGINE


MODEL RATED OUTPUT CURRENT (AMPS) RATED POWER (HP) NO. OF CYLIN- DERS SWEPT VOLUME (CC) SPECIFIC FUEL CONSUMP- TION (GM/ BHP-HR) ASPIRA- TION
KVA KW THREE PHASE
JVMG-25 25 20 35 32 2 2376 162 Natural
JVMG-30 30 24 42 41 3 3307 162 Natural
JVMG-35 35 28 49 46* 3 3307 162 Natural
JVMG-40 40 32 56 56 4 4561 159 Natural
JVMG-45 45 36 63 56 4 4561 159 Natural
JVMG-50 50 40 70 62* 4 4561 169 Natural
JVMG-65 65 52 90 84 4 4561 162 Turbo Charged
JVMG-82 82.5 66 114 106 6 6614 152 Turbo Charged
JVMG-100 100 80 138 125 6 6614 152 Turbo Charged
