16-Channel Classic Magnetic Stirrer

More Views

16-Channel Classic Magnetic Stirrer

Code:
16-Channel Classic Magnetic Stirrer
Features
  • 16 stirring positions with a possibility for Parallel experiments.
  • Stainless steel work plate covered with silicone film prevents skid
Advantages for the user
  • Multi-position magnetic stirrers minimize bench space
  • Anti-slip and Anti-corrosion silicone surface
Specifications:
• A space saving unit with 16 stirring positions and 4 independent speed control channels
• A wide range of speed from 0 to 1100rpm
• High magnetic adhesion prevents stirrer spin bar out of control
• Stainless steel work plate cover with silicone cushion, provid excellent performance of skid resistance
 Catalogue No LSMS-M-S16
 Dimension of work plate [W x D]  365×345mm
 Work plate material  Stainless steel with silicone cushion
 Motor type  DC motor
 Motor input power  12W
 Motor output power  4W
 Power  20W
 Voltage   100-120/200-240V, 50/60Hz
 Stirring positions  16 ( 4 channel )
 Max. stirring quantity [H2O]  0.4L×16
 Max. magnetic bar [length]  40mm
 Speed range  0-1100rpm
 Speed display  Scale
 Protection class  IP2X
 Dimension [W x D x H]  380×622×65mm
 Weight  6kg
 Permissible ambient temperature  and humidity  5-40°C, 80%



Description

Details

16-Channel Classic Magnetic Stirrer
Features
  • 16 stirring positions with a possibility for Parallel experiments.
  • Stainless steel work plate covered with silicone film prevents skid
Advantages for the user
  • Multi-position magnetic stirrers minimize bench space
  • Anti-slip and Anti-corrosion silicone surface
Specifications:
• A space saving unit with 16 stirring positions and 4 independent speed control channels
• A wide range of speed from 0 to 1100rpm
• High magnetic adhesion prevents stirrer spin bar out of control
• Stainless steel work plate cover with silicone cushion, provid excellent performance of skid resistance
 Catalogue No LSMS-M-S16
 Dimension of work plate [W x D]  365×345mm
 Work plate material  Stainless steel with silicone cushion
 Motor type  DC motor
 Motor input power  12W
 Motor output power  4W
 Power  20W
 Voltage   100-120/200-240V, 50/60Hz
 Stirring positions  16 ( 4 channel )
 Max. stirring quantity [H2O]  0.4L×16
 Max. magnetic bar [length]  40mm
 Speed range  0-1100rpm
 Speed display  Scale
 Protection class  IP2X
 Dimension [W x D x H]  380×622×65mm
 Weight  6kg
 Permissible ambient temperature  and humidity  5-40°C, 80%
