Hotplate Stirrers (Basic)

Code:
Hotplate Stirrers (Basic)
Easy to control with simple dial knobs for general lab heating and stirring applications.
Performance & Convenience
  • Integrated design of the heater and the top plate provides exceptional heat transfer rate and quick heat up capability.
  • Fast and precise stirring operations are enabled by BLDC motor and special magnet with extremely strong magnetic coupling power.
  • Instant halt of the stirring operation due to the exceptionally fast response characteristics.
  • Smooth-start mechanism provides virtually no decoupling of stir bars even with viscous media.
  • Large stirring capacity up to 20 liter in case of water.
  • Non-slip heating bath with concavo-convex bottom prevents unintentional slips of the bath. (optional)
  • A transparent safety shield protects users from liquid splashes. (optional)
  • Support rod allows for diverse flexibility in configuring other test equipment and accessories. (optional)
Safety
  • Built in thermal shutdown and current limit protection.
  • Hot top warning Indicator for preventing accidental injuries.
Model LSTM-14SB LSTM-14RB LSTM-17SB LSTM-17RB LSTM-18Q
Heating Temperature range (℃ / ℉) Max. 350 / 662
Control Scale
Heating power(W) 600 800
Stirring Speed range (rpm) 50 to 2,000
Capacity  (L / cu ft, H2O) 20 / 0.71
Magnetic bar, Max.
(ØxL, mm / Inch)
8 x 40 / 0.31 x 1.57
Safety Hot top indicator(℃ / ℉) Warning lamp (50 / 122)
Over temp. Top plate / Main body / PCB
Over current Current limit protection
Motor BLDC motor
Load, Max. (kg / Ibs) 25 / 55.12
Top plate Shape Round type Square type
Material Ceramic coated aluminum
Dimension
(Ø or WxD) (mm / inch)
140 / 5.51 170 / 6.69 180x180/ 7.08x7.08
Body Shape Straight body Round handles Straight body Round handles Straight body
Material Aluminum
Dimension
(WxDxH) (mm / inch)
161x290x100/ 6.34x11.42x3.94 210x294x99/ 8.27x11.57x3.9 191x330x101/ 7.52x12.99x3.98 240x324x100/ 9.45x12.76x3.94 209x326x102/ 8.22x12.83x4.0
Net weight (kg / Ibs) 2.8 / 6.17 3 / 6.61 3.5 / 7.72 3.6 / 7.94 3.8 / 8.37
Electrical requirements(230V, 50/60Hz) 3.0 A 4.0 A
※ Permissible environmental conditions: temperature (5-40℃) and relative humidity (up to 80%).
Description

Details

Hotplate Stirrers (Basic)
Easy to control with simple dial knobs for general lab heating and stirring applications.
Performance & Convenience
  • Integrated design of the heater and the top plate provides exceptional heat transfer rate and quick heat up capability.
  • Fast and precise stirring operations are enabled by BLDC motor and special magnet with extremely strong magnetic coupling power.
  • Instant halt of the stirring operation due to the exceptionally fast response characteristics.
  • Smooth-start mechanism provides virtually no decoupling of stir bars even with viscous media.
  • Large stirring capacity up to 20 liter in case of water.
  • Non-slip heating bath with concavo-convex bottom prevents unintentional slips of the bath. (optional)
  • A transparent safety shield protects users from liquid splashes. (optional)
  • Support rod allows for diverse flexibility in configuring other test equipment and accessories. (optional)
Safety
  • Built in thermal shutdown and current limit protection.
  • Hot top warning Indicator for preventing accidental injuries.
Model LSTM-14SB LSTM-14RB LSTM-17SB LSTM-17RB LSTM-18Q
Heating Temperature range (℃ / ℉) Max. 350 / 662
Control Scale
Heating power(W) 600 800
Stirring Speed range (rpm) 50 to 2,000
Capacity  (L / cu ft, H2O) 20 / 0.71
Magnetic bar, Max.
(ØxL, mm / Inch)
8 x 40 / 0.31 x 1.57
Safety Hot top indicator(℃ / ℉) Warning lamp (50 / 122)
Over temp. Top plate / Main body / PCB
Over current Current limit protection
Motor BLDC motor
Load, Max. (kg / Ibs) 25 / 55.12
Top plate Shape Round type Square type
Material Ceramic coated aluminum
Dimension
(Ø or WxD) (mm / inch)
140 / 5.51 170 / 6.69 180x180/ 7.08x7.08
Body Shape Straight body Round handles Straight body Round handles Straight body
Material Aluminum
Dimension
(WxDxH) (mm / inch)
161x290x100/ 6.34x11.42x3.94 210x294x99/ 8.27x11.57x3.9 191x330x101/ 7.52x12.99x3.98 240x324x100/ 9.45x12.76x3.94 209x326x102/ 8.22x12.83x4.0
Net weight (kg / Ibs) 2.8 / 6.17 3 / 6.61 3.5 / 7.72 3.6 / 7.94 3.8 / 8.37
Electrical requirements(230V, 50/60Hz) 3.0 A 4.0 A
※ Permissible environmental conditions: temperature (5-40℃) and relative humidity (up to 80%).
