Hotplate Stirrers (Basic)

Hotplate Stirrers (Basic)

More Views

Hotplate Stirrers (Basic)

Code:
Hotplate Stirrers (Basic)
  • Easy to control with simple dial knobs for general lab heating and stirring applications.
Performance & Convenience
  • Integrated design of the heater and the top plate provides exceptional heat transfer rate and quick heat up capability.
  • Fast and precise stirring operations are enabled by BLDC motor and special magnet with extremely strong magnetic coupling power.
  • Instant halt of the stirring operation due to the exceptionally fast response characteristics.
  • Smooth-start mechanism provides virtually no decoupling of stir bars even with viscous media.
  • Large stirring capacity up to 20 liter in case of water.
  • Non-slip heating bath with concavo-convex bottom prevents unintentional slips of the bath. (optional)
  • A transparent safety shield protects users from liquid splashes. (optional)
  • Support rod allows for diverse flexibility in configuring other test equipment and accessories. (optional)
Safety
  • Built in thermal shutdown and current limit protection.
  • Hot top warning Indicator for preventing accidental injuries.

Model LSTM-14SB LSTM-14RB LSTM-17SB LSTM-17RB LSTM-18Q
Heating Temperature range (℃ / ℉) Max. 350 / 662
Control Scale
Heating power(W) 600 800
Stirring Speed range (rpm) 50 to 2,000
Capacity  (L / cu ft, H2O) 20 / 0.71
Magnetic bar, Max.
(ØxL, mm / Inch)		 8 x 40 / 0.31 x 1.57
Safety Hot top indicator(℃ / ℉) Warning lamp (50 / 122)
Over temp. Top plate / Main body / PCB
Over current Current limit protection
Motor BLDC motor
Load, Max. (kg / Ibs) 25 / 55.12
Top plate Shape Round type Square type
Material Ceramic coated aluminum
Dimension
(Ø or WxD) (mm / inch)		 140 / 5.51 170 / 6.69 180x180/ 7.08x7.08
Body Shape Straight body Round handles Straight body Round handles Straight body
Material Aluminum
Dimension
(WxDxH) (mm / inch)		 161x290x100/ 6.34x11.42x3.94 210x294x99/ 8.27x11.57x3.9 191x330x101/ 7.52x12.99x3.98 240x324x100/ 9.45x12.76x3.94 209x326x102/ 8.22x12.83x4.0
Net weight (kg / Ibs) 2.8 / 6.17 3 / 6.61 3.5 / 7.72 3.6 / 7.94 3.8 / 8.37
Electrical requirements(230V, 50/60Hz) 3.0 A 4.0 A
※ Permissible environmental conditions: temperature (5-40℃) and relative humidity (up to 80%).

Cat. No. Ø (mm / inch) L (mm / inch)
LSBCW1513 8 / 0.31 13 / 0.51
LSBCW1515 8 / 0.31 15 / 0.59
LSBCW1522 8 / 0.31 22 / 0.86
LSBCW1525 8 / 0.31 25 / 0.98
LSBCW1528 8 / 0.31 28 / 0.10
LSBCW1538 8 / 0.31 38 / 1.49
LSBCW1541 8 / 0.31 41 / 1.61
LSBCW1551 8 / 0.31 51 / 2.00
LSBCW155110 10 / 0.39 51 / 2.00

Cylindrical magnetic stirring bar
Cat. No. Ø (mm / inch) L (mm / inch)
LSBCW11138 8 / 0.31 13 / 0.51
LSBCW11156 6 / 0.23 15 / 0.59
LSBCW11208 8 / 0.31 20 /  0.78
LSBCW11258 8 / 0.31 25 / 0.98
LSBCW11308 8 / 0.31 30 / 1.18
LSBCW1140 8 / 0.31 40 / 1.57
LSBCW1150 8 / 0.31 50 / 1.96

Oval magnetic stirring bar
Cat. No. Ø (mm / inch) L (mm / inch)
LSBCW1610 5 / 0.19 10 / 0.39
LSBCW1615 6 / 0.23 15 / 0.59
LSBCW1620 10 / 0.39 20 /  0.78
LSBCW162510 10 / 0.39 25 / 0.98
LSBCW1630 16 / 0.63 30 / 1.18
LSBCW1635 16 / 0.63 35 / 1.38
LSBCW1640 20 / 0.78 40 / 1.57
LSBCW1650 20 / 0.78 50 / 1.96

Description

Details

Hotplate Stirrers (Basic)
  • Easy to control with simple dial knobs for general lab heating and stirring applications.
Performance & Convenience
  • Integrated design of the heater and the top plate provides exceptional heat transfer rate and quick heat up capability.
  • Fast and precise stirring operations are enabled by BLDC motor and special magnet with extremely strong magnetic coupling power.
  • Instant halt of the stirring operation due to the exceptionally fast response characteristics.
  • Smooth-start mechanism provides virtually no decoupling of stir bars even with viscous media.
  • Large stirring capacity up to 20 liter in case of water.
  • Non-slip heating bath with concavo-convex bottom prevents unintentional slips of the bath. (optional)
  • A transparent safety shield protects users from liquid splashes. (optional)
  • Support rod allows for diverse flexibility in configuring other test equipment and accessories. (optional)
Safety
  • Built in thermal shutdown and current limit protection.
  • Hot top warning Indicator for preventing accidental injuries.

Model LSTM-14SB LSTM-14RB LSTM-17SB LSTM-17RB LSTM-18Q
Heating Temperature range (℃ / ℉) Max. 350 / 662
Control Scale
Heating power(W) 600 800
Stirring Speed range (rpm) 50 to 2,000
Capacity  (L / cu ft, H2O) 20 / 0.71
Magnetic bar, Max.
(ØxL, mm / Inch)		 8 x 40 / 0.31 x 1.57
Safety Hot top indicator(℃ / ℉) Warning lamp (50 / 122)
Over temp. Top plate / Main body / PCB
Over current Current limit protection
Motor BLDC motor
Load, Max. (kg / Ibs) 25 / 55.12
Top plate Shape Round type Square type
Material Ceramic coated aluminum
Dimension
(Ø or WxD) (mm / inch)		 140 / 5.51 170 / 6.69 180x180/ 7.08x7.08
Body Shape Straight body Round handles Straight body Round handles Straight body
Material Aluminum
Dimension
(WxDxH) (mm / inch)		 161x290x100/ 6.34x11.42x3.94 210x294x99/ 8.27x11.57x3.9 191x330x101/ 7.52x12.99x3.98 240x324x100/ 9.45x12.76x3.94 209x326x102/ 8.22x12.83x4.0
Net weight (kg / Ibs) 2.8 / 6.17 3 / 6.61 3.5 / 7.72 3.6 / 7.94 3.8 / 8.37
Electrical requirements(230V, 50/60Hz) 3.0 A 4.0 A
※ Permissible environmental conditions: temperature (5-40℃) and relative humidity (up to 80%).

Cat. No. Ø (mm / inch) L (mm / inch)
LSBCW1513 8 / 0.31 13 / 0.51
LSBCW1515 8 / 0.31 15 / 0.59
LSBCW1522 8 / 0.31 22 / 0.86
LSBCW1525 8 / 0.31 25 / 0.98
LSBCW1528 8 / 0.31 28 / 0.10
LSBCW1538 8 / 0.31 38 / 1.49
LSBCW1541 8 / 0.31 41 / 1.61
LSBCW1551 8 / 0.31 51 / 2.00
LSBCW155110 10 / 0.39 51 / 2.00

Cylindrical magnetic stirring bar
Cat. No. Ø (mm / inch) L (mm / inch)
LSBCW11138 8 / 0.31 13 / 0.51
LSBCW11156 6 / 0.23 15 / 0.59
LSBCW11208 8 / 0.31 20 /  0.78
LSBCW11258 8 / 0.31 25 / 0.98
LSBCW11308 8 / 0.31 30 / 1.18
LSBCW1140 8 / 0.31 40 / 1.57
LSBCW1150 8 / 0.31 50 / 1.96

Oval magnetic stirring bar
Cat. No. Ø (mm / inch) L (mm / inch)
LSBCW1610 5 / 0.19 10 / 0.39
LSBCW1615 6 / 0.23 15 / 0.59
LSBCW1620 10 / 0.39 20 /  0.78
LSBCW162510 10 / 0.39 25 / 0.98
LSBCW1630 16 / 0.63 30 / 1.18
LSBCW1635 16 / 0.63 35 / 1.38
LSBCW1640 20 / 0.78 40 / 1.57
LSBCW1650 20 / 0.78 50 / 1.96
