Magnetic Stirrer

Code:
Magnetic Stirrer

Magnetic stirrers are highly chemical resistant to acid, alkali and oil. Ideal for all types of laboratory stirring and heating applications. High level-of safety thanks to the improved heat control technology. These stirrers give high level of reliability even at low speed and high temperatures 'The stirring speed is controlled by electronic circuit and temperature is controlled by closed loop thermostat control.

  • Magnetic stirrers with new flat and round hot plate
  • Highly reliable temperature control
  • All units come with a heating power of 500 W for fast heating-up
  • High-efficiency motor with low power consumption
  • Wide speed range up to 1400 rpm
  • Excellent stirring results in volumes up to 10 liters (H20)
  • Enhanced heavy-duty stirring magnet drives stirring bars with ease
  • Maintenance-free motors with smooth start feature
  • Safety logic for Auto Cut Off of heating plate temperature when using digital temperature controller optional available for this model.
  • Stand support to save space and avoid additional accessories

Technical Data
MODEL LSMS-017
No. of stirring positin 1
Stirring quantity max. 20
Motor rating Input (W) 17
Motor Ratimg Output (W) 20
Speed Display none
Speed range 150-1400
Stirring Bath max (mm) 80
Heat Output (W) 500
Heat range
Heating Temperature range 40-200
Heat Control Accuracy
Safety Logic 300
Ext. Temperature Sensor N/A
Set up plate material alloy Aluminium
Hot plate dimensions (mm) 148 diameter
Permissible ambient temperature 5 to 40
Voltage (V) 220-240
Frequency (Hz) 50
Power Input (W) 520
Description

Details

Magnetic Stirrer

Magnetic stirrers are highly chemical resistant to acid, alkali and oil. Ideal for all types of laboratory stirring and heating applications. High level-of safety thanks to the improved heat control technology. These stirrers give high level of reliability even at low speed and high temperatures 'The stirring speed is controlled by electronic circuit and temperature is controlled by closed loop thermostat control.

  • Magnetic stirrers with new flat and round hot plate
  • Highly reliable temperature control
  • All units come with a heating power of 500 W for fast heating-up
  • High-efficiency motor with low power consumption
  • Wide speed range up to 1400 rpm
  • Excellent stirring results in volumes up to 10 liters (H20)
  • Enhanced heavy-duty stirring magnet drives stirring bars with ease
  • Maintenance-free motors with smooth start feature
  • Safety logic for Auto Cut Off of heating plate temperature when using digital temperature controller optional available for this model.
  • Stand support to save space and avoid additional accessories

Technical Data
MODEL LSMS-017
No. of stirring positin 1
Stirring quantity max. 20
Motor rating Input (W) 17
Motor Ratimg Output (W) 20
Speed Display none
Speed range 150-1400
Stirring Bath max (mm) 80
Heat Output (W) 500
Heat range
Heating Temperature range 40-200
Heat Control Accuracy
Safety Logic 300
Ext. Temperature Sensor N/A
Set up plate material alloy Aluminium
Hot plate dimensions (mm) 148 diameter
Permissible ambient temperature 5 to 40
Voltage (V) 220-240
Frequency (Hz) 50
Power Input (W) 520
