Slide Wire Wheatstone Bridge

Consists of a resistance wire with a sliding contact and a strip of aluminum to provide two “arms” of the bridge for known and unknown resistance. Strips of heavy aluminum are provided with a single gap in each of two arms for the resistance. All components are mounted on a heavy sheet metal base. With Instructions.

Ordering Information:
