Industrial Precision Balances ( 0.1g to 10 Kg )

Backlite LCD Display

• Customized, large, attractive LCD with multiparameter display illuminated by white backlite.

Bi directional RS 232 interface

• RS 232 port with selectable baud rate 4800,9600.

• Various interface formats adopting this Balance in a setup to replace any other leading international brand Balance.Can be configured for an USB interface using optional RS 232 to USB converter.

GSM function

• GSM function for paper & cloth quality checking.

Multiple Weighing Units

• Grams, Ounces, Troy Ounces, Carats, Mommes, Pennyweights, Grains, tola, Mesghal, Chinese taels.

Percentage Weighing

• Display of Reference weight, sample weight, % of sample with respect to reference weight

Piece Counting

• Parts calibration using preset quantity of samples or programmable quantity. Automatic count  correction for precise calibration.

Fill Mode

• 1 set point - Indication when sample weight exceeds the set limit.

• 2 set points – Indication when the sample weight is between the lower & upper limits.

Accumulation

• Storage of maximum 200 samples.

Multiple Printing Mode

• 0,1,2,3 modes for various formats.Pause in case data storage capacity in a Printer is less.

External Calibration

• Using preset weights.Known weights can be corrected to + 15 counts.

Response Time:

• User selectable – Slow / Normal /Fast.

Stability Band Width

• Stability indicator appears on display with counts variation + 1, + 2, +3, + 4.

Auto Zero Tracking

• User selectable 0,1,2,3

Return to Zero Tracking

• Variable: 0,1,2,3,4

Display Updation

• Speed setting : Fast / Normal.

Specifications :

Specifications :

• Taring Range : Up to full capacity

• Response time : 3-5 seconds

• Power Req : 90-250V, 50/60Hz, 10 Watt

• Operating Temperature : 10 to 45 deg C

Optional Features

• RS 232 to USB interface converter.

• ISO GLP compliance.

• Real time clock (RTC).

• Weigh below hook for density determination.

• Software for SQC (Statistical Quality Control) for Pharmaceutical Industries.

• Vacuum fluorescent display (VFD).
