Ecg Machine Three Channel

Features

• Safety Type Class I, Type CF applied part, which has defibrillation-proof applied part

• Lead Standard 12 leads

• input way: Floating and defibrillation protection

• Patient leak current <10µA

• Sampling rate 1000Hz

• A/D conversion 12bit

• Frequency response 0.05Hz~150Hz (-3dB, + 0.4dB)

• Time constant >3.2s

• CMRR ＞60dB, ＞100dB( Add filter)

• Enduring polarization voltage: ±500mV

• Noise level ≤15µVp-p

• EMG interference filter 25Hz/35Hz (-3dB)

• AC filter 50Hz/60Hz (≥20dB)

• Recording way Thermal printing system(8spots/mm)

• Recording paper 80mm(W)×20m(L)

• Sensitivity 5mm/mV 10mm/mV 20mm/mV 40mm/mV Auto

• Paper speed: Auto-mode: 25mm/s, 50mm/s Rhythm-mode:25mm/s, 50mm/s Manual-mode:5mm/s, 6.25mm/s, 10mm/s, 12.5mm/s, 25mm/s, 50mm/s

• Power supply: AC:220V，50Hz（110V ,60 Hz）DC: 7.4V, 3700 mAh rechargeable lithium battery

• Fuse Specification: 2 pcs φ5×20mm AC time lag; T1.6A/250V(Power Supply:220V)

• Size: 315mm(L) x 215mm(W) x 77mm(H) Supply:220V)

• Net Weight 2.25Kg
