Multi Parameter Patient Monitor

Features :

• 12.1” Colour TFT LCD display with
•  waveforms upto 8 Channels
• Portable , streamline handle designPortable , streamline handle design
• Monitor measures from Adult to Neonates
• easurement of one channel ECG anytime, anywhere you like
• Display of ECG waveform, heart rate, analysis results and battery status on the backlit LCD
• Measurement results transmission to PC by USB mode
• Auto power-off while no key is pressed in 30 seconds
• Auto-evaluation based on detected heart data
• Dual measuring modes
• 2 batteries can take at least 500 times measurement
• Data Review freely

ECG

• 5-lead or 12-lead selectable
• Input: 5-lead: RA; LA; RL; LL; V or R; L; N; F; C
• Lead selection: I; II; III; avR; avL; avF; Vx; CAL
• Gain selection:×0.25,×0.5,×1,×2,auto
• Sweep speed: 12.5mm/s, 25mm/s, 50mm/s
• Accuracy: ±1bpm or ±1%, whichever is greater
• Protection: Withstand 4000V AC/50Hz voltage in isolation against electrosurgical and defibrillation
• Calibration signal: 1mV±5%
• Operation modes: Diagnostic, Monitor, Surgery
• Heart rate range: Adult: 15-300bpm Paediatric/ Neonatal: 15-350bpm
• 2 batteries can take at least 500 times measurement
• Measurement range: -2.0mV~2.0mV
• S-T detection: YES, Arrhythmia analysis: YES
• Alarm: YES, audible and visual alarm, alarm events recallable

NIBP

• Method: Oscillometry
• Operation modes: Manual/Automatic/STAT
• Measurement unit: mmHg/KPa selectable
• Gain selection:×0.25,×0.5,×1,×2,auto
• Measurement types: Systolic, Diastolic, Mean
• Measurement range: Adult: 10-270mmHg
• Over-pressure protection: YES
• Resolutionl: 1mmHg
• Accuracy: The mean error shall be less than ±5 mmHg ,the standard deviation shall be less than ±8mmHg
• Alarm: Systolic,Diastolic,Mean

SPO2

• Measurement range: 0-100%
• Accuracy: ±2%(70~100%);0~69% unspecified
• Alarm range: 0-100%

Respiration

• Method: RA-LL impedance
• Measurement range:Adult: 0-120rpm, paediatric/neonatal:0-150rpm
• Apnea alarm: YES

Temperature

• Resolution: 0.1 °C
• Channel:Dual-channel
• Measurement range: 0-50 °C

IBP

• Channel: 2 channels
• Pressure transducer:Sensitivity: 5( mV/V/mmHg)
• Transducer sites: ART, PA, CVP, RAP, LAP, ICP
• Alarm range: -10~300mmHg

* Specification of JFPO-80 and JFPO-90 are same

Catalogue No

JFPO-80 & JFPO-90
