Electric-Heated Vertical Steam Sterilizer

More Views

Electric-Heated Vertical Steam Sterilizer

Code:
Electric-Heated Vertical Steam Sterilizer
(Fully automatic microcomputer)

Characteristics:
  • Fully stainless steel structure
  • Hand wheel type of quick-open door structure
  • Door safety lock system
  • Automatically controlled by computer
  • Digital display of working status, touch of key
  • Over temperature over pressure auto-protection
  • Steam-water inner circulation system: no steam discharge, and the environment for sterilizing will be clean and dry
  • Self-inflating type seal
  • Safe protection of water lacking
  • The drying system is optional, which can be equipped according to the customers' request
  • Automatically shut off with beep reminding after sterilization
  • 12.With two stainless steel sterilizing baskets

Technical Data:
Technical Data JLS-35HG JLS-50HG JLS-75HG JLS-100HG
Chamber volume 35L(φ318×450)mm 50L(φ340×550)mm 75L(φ400×600)mm 100L(φ440×650)mm
working pressure 0.22MPa
Working temperature 134℃
Max working pressure 0.23Mpa
Heat average ≤±1℃
Timer 0~99min或0~99hour59 min
Adjustment of temperature 0~134℃
Power 2.5KW/AC220V.50Hz 3KW /AC220V.50Hz 4.5KW /AC220V.50Hz
Overall dimension 600×410×1030mm 650×410×1140 mm 690×470×1140 mm 730×510×1270 mm
Transport dimension 730×500×1170 mm 730×500×1290 mm 760×550×1290 mm 820×600×1380 mm
G.W/N.W 96Kg/ 77Kg 102Kg/ 83Kg 120Kg/98Kg 135/110Kg

Description

Details

Electric-Heated Vertical Steam Sterilizer
(Fully automatic microcomputer)

Characteristics:
  • Fully stainless steel structure
  • Hand wheel type of quick-open door structure
  • Door safety lock system
  • Automatically controlled by computer
  • Digital display of working status, touch of key
  • Over temperature over pressure auto-protection
  • Steam-water inner circulation system: no steam discharge, and the environment for sterilizing will be clean and dry
  • Self-inflating type seal
  • Safe protection of water lacking
  • The drying system is optional, which can be equipped according to the customers' request
  • Automatically shut off with beep reminding after sterilization
  • 12.With two stainless steel sterilizing baskets

Technical Data:
Technical Data JLS-35HG JLS-50HG JLS-75HG JLS-100HG
Chamber volume 35L(φ318×450)mm 50L(φ340×550)mm 75L(φ400×600)mm 100L(φ440×650)mm
working pressure 0.22MPa
Working temperature 134℃
Max working pressure 0.23Mpa
Heat average ≤±1℃
Timer 0~99min或0~99hour59 min
Adjustment of temperature 0~134℃
Power 2.5KW/AC220V.50Hz 3KW /AC220V.50Hz 4.5KW /AC220V.50Hz
Overall dimension 600×410×1030mm 650×410×1140 mm 690×470×1140 mm 730×510×1270 mm
Transport dimension 730×500×1170 mm 730×500×1290 mm 760×550×1290 mm 820×600×1380 mm
G.W/N.W 96Kg/ 77Kg 102Kg/ 83Kg 120Kg/98Kg 135/110Kg
