Superklave High Pressure
(AVAILABLE IN HIGH PRESSURE UPTO 30 PSI)
(CE, ISO 9001:2008, ISO 18001:2007, ISO 14001:2004, ISO 13485:2003 & GMP CERTIFIED)

• "Medberg" SUPERKLAVE are most ideal for critical applications requiring assured and reliable total destruction of all living micro-organisms.

CONSTRUCTION & SALIENT FEATURES

• Inner chamber, outer chamber and support ring are fully made of stainless steel (SS-304 grade).
• Heaters cover stand and carrier/bucket are made of Stainless Steel.
• Lid made of thick machined Stainless Steel plate.
• Radial locking lid ensures user safety and safe locking.
• Lid is fitted with Pressure Gauge, Spring Loaded Safety Valve, extra Safety Valve, Manual Exhaust Valve, Vacuum Breaker-cum-Purge Valve as a safety device and water level indicator.
• Drain Valve facilitates easy cleaning of the chamber.
• SILICON DOOR SEAL / GASKET.
• All internal joints are argon arc welded, ground and polished to give crevice free internals.
• Processor based Controller with time and temperature programmable by user.
• Class 'A' Platinum (Pt-100) sensor, enabling precise and accurate monitoring.
• Low water level alarm and cut off for safety of heater.
• Sensor open alarm and display.
• End of cycle buzzer to alert the user and auto reset.
• Miniature Circuit Breaker for MAINS On/Off plus safety of control panel.
• Solenoid Valve for automatic purging and exhaust (user settable).
• Industrial grade energy efficient heaters reduce power bills drastically.
• These are fully automatic models requiring no human intervention till a full sterilization cycle is over.
• A heavy duty high pressure system to work on a maximum pressure 30 psi.

CONTROL PANEL & SWITCHGEARS

• Features a COMPACT SINGLE BOX PLC with built in HUMAN MACHINE INTERFACE.
• 7 segment LED interface has 3 displays (3+4+4) digit +5keys.
• Processor based Controller with time and temperature programmable by user.
• Class 'A' Platinum (PT-100) sensor, enabling precise and accurate monitoring.
• Digital input 6 PNP-11 to 30VDC and analog input 2 CH-TC/RTD/0-10V/0-29 (User selectable).
• 4 relay digital output and 1CH (0-10v)/0-20 ma Analogue output .
• Standard Validation Port for insertion of probes for external Multichannel Temperature Sensors / Scanners for validation qualification and documentation purposes.

(OPTION)

• A Double Tier Password Data Security Lock for data security.
• It is very important to ensure that all the trapped air is removed before activation of a sterilization cycle, as hot air is a very poor medium for achieving sterility. Steam at 1340C can achieve in THREE MINUTES the same sterility that hot air at 1600C takes two hours to achieve.
• To enhance the high pressure sterilization at 1340C multiple/series of STEAM PULSES are carried out, through our SUPER SMART PLC+HMI, in which the chamber is alternately PRESSURIZED AND DEPRESSURIZED (THERMAL PURGING) to achieve a total STERILE CHAMBER ready to for actuation of Main sterilization process.
• Digital pressure indicator displayed pressure directly into main control panel.

Technical Specifications & Ordering Informations

OPTIONAL

• Communication Port (Option) is available at an extra, through a RS-232 (Slave) or RS-485 (Slave) via MODBUS-RTU, complete with USB Communication Data cable and single user software (MODBUS).
• Class 5 Emulating Indicator (pack of 400 strips)
• SOFKLAVE 2000:

1. A semiautomatic MICRO CONTROL system with total 4 fixed programs (selectable manually) with digital temperature control and CENTRONIC OUTPUT PORT for on-line printing.
2. do- same as above but with 5 fixed programs and one flexible sterilization cycle with digital temperature control and CENTRONIC OUTPUT PORT for on line Printing.

• SOFKLAVE 2000(PRO) : An INEGRATED FULLY AUTOMATIC LCD AUTO-CONTROL PROGRAMME with PLC and built in HMI controller having 5 fixed programmes and one flexible sterilization cycle with 16x2 alphanumeric display and CENTRONIC OUTPUT PORT for on-line printing.
• Multipoint Temperature/Pressure Scanner with LCD display and CENTRONIC port for printer. Total 6 scanning points with five for temperature and on for pressure. Supplied complete with Nos. RTD probes and communication cable for attaching to printer.
