Vertical Pressure Steam Sterilizer

Vertical Pressure Steam Sterilizer

More Views

Vertical Pressure Steam Sterilizer

Code:
 Vertical Pressure Steam Sterilizer
Characteristics：
  • The chamber of the sterilizer is made of stainless steel
  • Indicator light indicates working state
  • Over temperature & over pressure auto-protection
  • Safe protection of water lacking
  • Double scale indication pressure gauge
  • Automatically shut off with beep reminding after sterilization
  • Easy to operate,safe and reliable
  • With two stainless steel sterilizing baskets
TECHNICAL DATA:
Technical data JLS-50HV JLS-75HV
Sterilizing chamber  volume 50L(φ340×550)mm 75L(φ400×600)mm
working pressure 0.22MPa
working  temperature 134℃
Max.working pressure 0.23 Mpa
Heat averag ≤±1℃
Time of sterilization 1～99min
Adjustment of temperature 0～134℃
Power 3000W/AC220V.50Hz 4500W/AC220V.50Hz
Dimension 690×470×1140(mm) 730×510×1270(mm)
Transport dimension 760×550×1290(mm) 820×600×1380(mm)
G.W/N.W 120Kg/ 100Kg 140Kg/118Kg
Description

Details

 Vertical Pressure Steam Sterilizer
Characteristics：
  • The chamber of the sterilizer is made of stainless steel
  • Indicator light indicates working state
  • Over temperature & over pressure auto-protection
  • Safe protection of water lacking
  • Double scale indication pressure gauge
  • Automatically shut off with beep reminding after sterilization
  • Easy to operate,safe and reliable
  • With two stainless steel sterilizing baskets
TECHNICAL DATA:
Technical data JLS-50HV JLS-75HV
Sterilizing chamber  volume 50L(φ340×550)mm 75L(φ400×600)mm
working pressure 0.22MPa
working  temperature 134℃
Max.working pressure 0.23 Mpa
Heat averag ≤±1℃
Time of sterilization 1～99min
Adjustment of temperature 0～134℃
Power 3000W/AC220V.50Hz 4500W/AC220V.50Hz
Dimension 690×470×1140(mm) 730×510×1270(mm)
Transport dimension 760×550×1290(mm) 820×600×1380(mm)
G.W/N.W 120Kg/ 100Kg 140Kg/118Kg
