Pure Steam Sterilizer

Pure Steam Sterilizer

More Views

Pure Steam Sterilizer

Code:
Pure Steam Sterilizer

This series of pulsation vacuum sterilizer applies saturated steam as its sterilization medium. The saturated steam releases a large amount of latent heated physical properties in the stage of condensation, which presents items to be sterilized with a state of high temperature and humidity. After a period of insulation in such status, sterilization is achieved. The application of pulsating vacuum exhausting has successfully eliminated temperature influence from cold air, and helping the sterilized items to be dried by means of vacuum and dehumidification between the jacket layers.

Applicable for equipment and devices requiring high temperature sterilization and dry cooling process for products like sterile clothing and filling apparatus, which are usually equipped in areas where sterilization requirements reach Level 100 and other areas requiring high environmental standards. It has been widely used in pharmaceutical, medical, and scientific research projects.

Main Parameters and Utilities
Design Pressure 0.245 MPa
 Design Temperature 1390 C
Vacuum -0.09 MPa
Water Source Pressure 0.15-0.3 MPa
Steam Pressure 0.3-0.7 MPa
Working Pressure 0.225 MPa
Working Temperature 105-1340C
Temperature Equilibrium ≤± 10C
Compressed Air Pressure 0.3-0.7 MPa
Power AC 380V; 50 Hz

Specifications & Ordering Details
Catalogue No

Overall Size
 L x W x H (mm)
Chamber Size
 L x W x H (mm)

Steam
Consumption (Kg)

Tap Water
Consumption (Kg/ cycle)

Power (KW)

Net Weight (KG)
JWG-C025 1100 X 1350 X 1900X 800 X 600 X 600 18 35 2+ 900
JWG-C036 1300 X 1350 X 1900 1000 X 600 X 600 25 40 2+ 1000
JWG-C06 1500 X 1360 X 1950 1200 X 610 X 910 30 45 3+ 1400
JWG-C08 1800 X 1360 X 1950 1500 X 610 X 910 40 50 3 1600
JWG-C12 1750 X 1440 X 1950 1450 X 680 X 1180 48 55 4 1800
JWG-C15 2150 X 1440 X 1950 1850 X 680 X 1180 55 60 4 2000
JWG-C20 1950 X 1750 X 2200 1600 X 900 X 1400 65 65 4.5 2500
JWG-C25 2300 X 1750 X 2200 1950 X 900 X 1400 75 75 6 3000
JWG-C30 2700 X 1750 2400 X 900 X 1400 90 90 8 3500

Structure and Characteristic of The Equipment
Body of the sterilizer:
  • It is designed and manufactured in accordance with GB150 "the Pressure Vessel”, and TSG R0004-2009 the “Safety and Technology Specification for Fixed Monitor Pressure Vessels” and related inspection procedures.
  • Tank of the horizontal rectangular double-deck structure is made from S31603.
  • Door sealing: Pneumatic sealing; both doors are interlocked and completely conform to the requirements of the specification.
  • The equipment has standard GMP authentication interface.
Sterilizer piping system: the pipeline is designed with the best configuration. By employing imported parts and quality domestic brands into main components, this system presents online sterilization option.
Sterilizer control system: with the adoption of Siemens PLC plus Siemens touch screen, this system is easy to implement the program selection, parameter setting, equipment operation, report processing and other functions. It has perfect safety measures. The F0 value and the temperature time gives double guarantee for sterilization. A single parameter control is also available. It has a perfect sterilization records
Description

Details

Pure Steam Sterilizer

This series of pulsation vacuum sterilizer applies saturated steam as its sterilization medium. The saturated steam releases a large amount of latent heated physical properties in the stage of condensation, which presents items to be sterilized with a state of high temperature and humidity. After a period of insulation in such status, sterilization is achieved. The application of pulsating vacuum exhausting has successfully eliminated temperature influence from cold air, and helping the sterilized items to be dried by means of vacuum and dehumidification between the jacket layers.

Applicable for equipment and devices requiring high temperature sterilization and dry cooling process for products like sterile clothing and filling apparatus, which are usually equipped in areas where sterilization requirements reach Level 100 and other areas requiring high environmental standards. It has been widely used in pharmaceutical, medical, and scientific research projects.

Main Parameters and Utilities
Design Pressure 0.245 MPa
 Design Temperature 1390 C
Vacuum -0.09 MPa
Water Source Pressure 0.15-0.3 MPa
Steam Pressure 0.3-0.7 MPa
Working Pressure 0.225 MPa
Working Temperature 105-1340C
Temperature Equilibrium ≤± 10C
Compressed Air Pressure 0.3-0.7 MPa
Power AC 380V; 50 Hz

Specifications & Ordering Details
Catalogue No

Overall Size
 L x W x H (mm)
Chamber Size
 L x W x H (mm)

Steam
Consumption (Kg)

Tap Water
Consumption (Kg/ cycle)

Power (KW)

Net Weight (KG)
JWG-C025 1100 X 1350 X 1900X 800 X 600 X 600 18 35 2+ 900
JWG-C036 1300 X 1350 X 1900 1000 X 600 X 600 25 40 2+ 1000
JWG-C06 1500 X 1360 X 1950 1200 X 610 X 910 30 45 3+ 1400
JWG-C08 1800 X 1360 X 1950 1500 X 610 X 910 40 50 3 1600
JWG-C12 1750 X 1440 X 1950 1450 X 680 X 1180 48 55 4 1800
JWG-C15 2150 X 1440 X 1950 1850 X 680 X 1180 55 60 4 2000
JWG-C20 1950 X 1750 X 2200 1600 X 900 X 1400 65 65 4.5 2500
JWG-C25 2300 X 1750 X 2200 1950 X 900 X 1400 75 75 6 3000
JWG-C30 2700 X 1750 2400 X 900 X 1400 90 90 8 3500

Structure and Characteristic of The Equipment
Body of the sterilizer:
  • It is designed and manufactured in accordance with GB150 "the Pressure Vessel”, and TSG R0004-2009 the “Safety and Technology Specification for Fixed Monitor Pressure Vessels” and related inspection procedures.
  • Tank of the horizontal rectangular double-deck structure is made from S31603.
  • Door sealing: Pneumatic sealing; both doors are interlocked and completely conform to the requirements of the specification.
  • The equipment has standard GMP authentication interface.
Sterilizer piping system: the pipeline is designed with the best configuration. By employing imported parts and quality domestic brands into main components, this system presents online sterilization option.
Sterilizer control system: with the adoption of Siemens PLC plus Siemens touch screen, this system is easy to implement the program selection, parameter setting, equipment operation, report processing and other functions. It has perfect safety measures. The F0 value and the temperature time gives double guarantee for sterilization. A single parameter control is also available. It has a perfect sterilization records
