Laboratory Centrifuge (General Purpose) (4400 R.P.M)

Laboratory Centrifuge (General Purpose) (4400 R.P.M)

More Views

Laboratory Centrifuge (General Purpose) (4400 R.P.M)

Code:
Laboratory Centrifuge (General Purpose) (4400 R.P.M)
Microprocessor Based, Digital
Specifications
  • Compact Laboratory Centrifuge Machine, Microprocessor based, Digital.
  • Body made of rust proof ABS Plastic injection moulding with metallic protection bowl.
  • Lid lock for safe drive.
  • Equipped with 0-99 minute timer.
  • 2 lines of 16 character LCD display of r.p.m., R.c.f, for set and run time.
  • Programmable speed regulator from 500 to 4400 rpm in interval of 100 rpm.
  • Last test parameter recall and displays automatically on LCD
Technical Parameters
Catalogue No. JT-4M
Max. Speed 4400 r.p.m.
Motor Universal Motor (with carbon brushes) 1/8 H.P.
Power AC 220V 50Hz ±10%
Dimension of Machine L = 395mm, W = 360mm, H = 280mm
Dimension of outer box 510 x 510 x 390mm
Net Weight 12.5 kg. Approx.
Gross Weight with box  14 Kg.
Current 220 volts, 50Hz A.C.

The machine comes with any one rotor head, to be selected by customer from below mentioned table.
Model Type Nos. of holes x Tube volume
JT-4MA Swing out 8x15ml
JT-4MB Swing out 16 x vacutainers
JT-4MC Swing out 16 x 12x75mm / 12x100mm borosil tubes
JT-4MD Angle 12 x 15ml.

Standard Accessories & Packing
  • The above mentioned rotor heads are completed with S.S. tube carriers, suitable Glass/PVC centrifugal tubes, head puller, spanner and rubber cushions.
  • Machine is well packed in 5 ply corrugated box.
Description

Details

Laboratory Centrifuge (General Purpose) (4400 R.P.M)
Microprocessor Based, Digital
Specifications
  • Compact Laboratory Centrifuge Machine, Microprocessor based, Digital.
  • Body made of rust proof ABS Plastic injection moulding with metallic protection bowl.
  • Lid lock for safe drive.
  • Equipped with 0-99 minute timer.
  • 2 lines of 16 character LCD display of r.p.m., R.c.f, for set and run time.
  • Programmable speed regulator from 500 to 4400 rpm in interval of 100 rpm.
  • Last test parameter recall and displays automatically on LCD
Technical Parameters
Catalogue No. JT-4M
Max. Speed 4400 r.p.m.
Motor Universal Motor (with carbon brushes) 1/8 H.P.
Power AC 220V 50Hz ±10%
Dimension of Machine L = 395mm, W = 360mm, H = 280mm
Dimension of outer box 510 x 510 x 390mm
Net Weight 12.5 kg. Approx.
Gross Weight with box  14 Kg.
Current 220 volts, 50Hz A.C.

The machine comes with any one rotor head, to be selected by customer from below mentioned table.
Model Type Nos. of holes x Tube volume
JT-4MA Swing out 8x15ml
JT-4MB Swing out 16 x vacutainers
JT-4MC Swing out 16 x 12x75mm / 12x100mm borosil tubes
JT-4MD Angle 12 x 15ml.

Standard Accessories & Packing
  • The above mentioned rotor heads are completed with S.S. tube carriers, suitable Glass/PVC centrifugal tubes, head puller, spanner and rubber cushions.
  • Machine is well packed in 5 ply corrugated box.
