Optima MAX-XP

Optima MAX-XP

More Views

Optima MAX-XP

Code:
Optima MAX-XP
The latest in tabletop ultracentrifuge technology
The OptimaTM MAX-XP tabletop ultracentrifuge is a power-packed solution that delivers fast, efficient separations from samples as small as 175 μl up to 32.4 ml and at speeds of up to 150,000 RPM and more than 1,000,000 x g.
 Every detail of the Optima MAX-XP is designed with the user in mind–from the system's compact design, versatility and quiet operation to advanced multi-lingual software.
Optima MAX-XP  Ultracentrifuge System Specifications
Model No Optima-MAX-XP
UNSPSC 41103907
Height 34.5 cm (13.6 in) front left; 39.4 cm (15.5 in) rear right
Width 73.9 cm (29.1 in)
Depth 61.7 cm (24.3 in)
Weight 105 kg (230 lb)
Approximate acceleration time 10 acceleration profiles
Approximate deceleration time 11 acceleration profiles
Electrical requirements 220/240 V, 50 Hz; 120 V, 50/60 Hz; 100 V, 50/60 Hz
g Force 1,019,000 x g (with MLA-130 rotor)
Max speed 150,000 rpm (with MLA-150 rotor)
Max heat dissipation (steady-state conditions) 0.7 kW (2,400 BTU/hr)
Noise Level 1m in front of centrifuge < 47 dBA
Refrigeration system Solid state, thermoelectric temperature control system with forced air, no coolant, no CFCs/ODCs
Set speed Actual rotor speed ± 50 rpm of set speed
Set temperature  0°C to 40°C in 1° increments
Speed range 5,000 to 150,000 rpm
Drive type Variable frequency induction drive, rotor overspeed ID
Temperature control ± 2°C of set temperature
Ambient temperature range 15 to 35°C ambient
User-settable programs All user programs have up to 5 steps each
Clearances required 7.6 cm (3.0 in) both sides and rear
Time-Actual display Indicates run time remaining
Vacuum Moisture-purging vacuum system
Display Full-color LCD touch screen

Description

Details

Optima MAX-XP
The latest in tabletop ultracentrifuge technology
The OptimaTM MAX-XP tabletop ultracentrifuge is a power-packed solution that delivers fast, efficient separations from samples as small as 175 μl up to 32.4 ml and at speeds of up to 150,000 RPM and more than 1,000,000 x g.
 Every detail of the Optima MAX-XP is designed with the user in mind–from the system's compact design, versatility and quiet operation to advanced multi-lingual software.
Optima MAX-XP  Ultracentrifuge System Specifications
Model No Optima-MAX-XP
UNSPSC 41103907
Height 34.5 cm (13.6 in) front left; 39.4 cm (15.5 in) rear right
Width 73.9 cm (29.1 in)
Depth 61.7 cm (24.3 in)
Weight 105 kg (230 lb)
Approximate acceleration time 10 acceleration profiles
Approximate deceleration time 11 acceleration profiles
Electrical requirements 220/240 V, 50 Hz; 120 V, 50/60 Hz; 100 V, 50/60 Hz
g Force 1,019,000 x g (with MLA-130 rotor)
Max speed 150,000 rpm (with MLA-150 rotor)
Max heat dissipation (steady-state conditions) 0.7 kW (2,400 BTU/hr)
Noise Level 1m in front of centrifuge < 47 dBA
Refrigeration system Solid state, thermoelectric temperature control system with forced air, no coolant, no CFCs/ODCs
Set speed Actual rotor speed ± 50 rpm of set speed
Set temperature  0°C to 40°C in 1° increments
Speed range 5,000 to 150,000 rpm
Drive type Variable frequency induction drive, rotor overspeed ID
Temperature control ± 2°C of set temperature
Ambient temperature range 15 to 35°C ambient
User-settable programs All user programs have up to 5 steps each
Clearances required 7.6 cm (3.0 in) both sides and rear
Time-Actual display Indicates run time remaining
Vacuum Moisture-purging vacuum system
Display Full-color LCD touch screen
