Digital Microscope

Digital Microscope

More Views

Digital Microscope

Code:
Digital Microscope

We are India based digital microscope manufacturers, exports and suppliers, we export digital microscopes worldwide apart from supplying digital microscope in India.

Digital Eyepiece camera 1.3 MP, USB 2.0
Sensor Parameter  1/2″ 1.3MP CMOS
Resolution  1280*1024
USB port  USB 2.0, 480 MB /s
Frame Rate 16 f/s @ 1280*1024
Preview Model 1280*1024, 640*480, 320*240
Pixel Size  5.2μm *5.2μm
Sensitivity 1.8 V/lux-sec@550nm
Spectrum response  400nm—1000nm
Shutter Type White ERS(electronic rolling shutter)
Balance  Auto
The Length of USB  1.5 meter
O/P compatibility  Windows–XP2, 7 and 8
Power supply  USB port
Tube diameter  23.2 mm or 30.00mm
Connection  Ocular tube or C-mount
Uniform focusing  YES
Optical magnification  10X
Rate of field  1/3
Matching lens  Yes

Function of software:
Image file management  set up, open up, save, lead in image file.
Image capture  Switch, setting, shoot, measure, full screen view.
Image edit  picture turn, zoom, cut, modify, email, print
Resolution of display  1280*1024
Resolution of picture  1280*1024
Resolution of video  1280*1024
Weight of device  0.10㎏

Ordering Details:
Catalogue No Description
JMVV-1300 Digital Microscope

Description

Details

Digital Microscope

We are India based digital microscope manufacturers, exports and suppliers, we export digital microscopes worldwide apart from supplying digital microscope in India.

Digital Eyepiece camera 1.3 MP, USB 2.0
Sensor Parameter  1/2″ 1.3MP CMOS
Resolution  1280*1024
USB port  USB 2.0, 480 MB /s
Frame Rate 16 f/s @ 1280*1024
Preview Model 1280*1024, 640*480, 320*240
Pixel Size  5.2μm *5.2μm
Sensitivity 1.8 V/lux-sec@550nm
Spectrum response  400nm—1000nm
Shutter Type White ERS(electronic rolling shutter)
Balance  Auto
The Length of USB  1.5 meter
O/P compatibility  Windows–XP2, 7 and 8
Power supply  USB port
Tube diameter  23.2 mm or 30.00mm
Connection  Ocular tube or C-mount
Uniform focusing  YES
Optical magnification  10X
Rate of field  1/3
Matching lens  Yes

Function of software:
Image file management  set up, open up, save, lead in image file.
Image capture  Switch, setting, shoot, measure, full screen view.
Image edit  picture turn, zoom, cut, modify, email, print
Resolution of display  1280*1024
Resolution of picture  1280*1024
Resolution of video  1280*1024
Weight of device  0.10㎏

Ordering Details:
Catalogue No Description
JMVV-1300 Digital Microscope
