Digital Microscope

Digital Microscope

More Views

Digital Microscope

Code:
Digital Microscope

Our  Digital Microscope are world class microscope, we are manufacturers of JMVV-5000 digital microscopes, and we export digital microscope worldwide

Digital Eyepiece camera 5.0 MP, USB 2.0
Sensor Parameter  1/2.5″ 5.0MP CMOS
Resolution  2560*1944
USB port  USB 2.0
Frame Rate 3.75fps for 5.0 MP
Preview Model  2560*1944, 2048*1536,1280×1024 ,1024×768
Pixel Size  2.2μm *2.2μm
Color Filter RGB Bayer Pattern
White Balance  Auto
The Length of USB  1.5 meter
O/P compatibility  Windows–XP2, 7 and 8
Power supply  USB port
Tube diameter  23.2 mm or 30.00mm
Connection  Ocular tube or C-mount
Uniform focusing  YES
Optical magnification  10X
Rate of field  1/3
Matching lens  Yes

Function of software:
Image file management  set up, open up, save, lead in image file.
Image capture  Switch, setting, shoot, measure, full screen view.
Image edit  picture turn, zoom, cut, modify, email, print
Resolution of display  2560*1944
Resolution of picture  2560*1944
Resolution of video  2560*1944
Weight of device  0.10㎏

Ordering Details:
Catalogue No Description
JMVV-5000 Digital Microscope
Description

Details

Digital Microscope

Our  Digital Microscope are world class microscope, we are manufacturers of JMVV-5000 digital microscopes, and we export digital microscope worldwide

Digital Eyepiece camera 5.0 MP, USB 2.0
Sensor Parameter  1/2.5″ 5.0MP CMOS
Resolution  2560*1944
USB port  USB 2.0
Frame Rate 3.75fps for 5.0 MP
Preview Model  2560*1944, 2048*1536,1280×1024 ,1024×768
Pixel Size  2.2μm *2.2μm
Color Filter RGB Bayer Pattern
White Balance  Auto
The Length of USB  1.5 meter
O/P compatibility  Windows–XP2, 7 and 8
Power supply  USB port
Tube diameter  23.2 mm or 30.00mm
Connection  Ocular tube or C-mount
Uniform focusing  YES
Optical magnification  10X
Rate of field  1/3
Matching lens  Yes

Function of software:
Image file management  set up, open up, save, lead in image file.
Image capture  Switch, setting, shoot, measure, full screen view.
Image edit  picture turn, zoom, cut, modify, email, print
Resolution of display  2560*1944
Resolution of picture  2560*1944
Resolution of video  2560*1944
Weight of device  0.10㎏

Ordering Details:
Catalogue No Description
JMVV-5000 Digital Microscope
Additional Information

Additional Information

Code No
