LCD Digital Microscope

Specification:

• Objective: All objectives are antifungal coated long barrel at the highest numerical aperture such as(Plan) PL4X NA0.10, PL 10X NA0.25, PL40X NA0.65(S.L.) and PL100X NA 1.25 oil immersion(S.L.) for brilliant.

• Eye Pieces: High eye point antifungal and antireglected extra wide field 10x/20mm paired eyepiece.

• Trinocular Head: All prism have anti-reflected and antifungal coatings. Having 30o inclination, 360o rotatable.

• Nose piece: A reversed type nosepiece running on ball-bearing balls ensures a smooth motion.

• Mechanical Stage : Co-axial coarse & fine focusing mechanism based on four steps reduction gears system which runs on ball-bearing guide ways, is provided with special tension adjustment rings. Stopper system is provided so that the slides may not get damage.

• Condenser: Abbe’s condenser NA 1.25, rack & Pinion adjustment.

• Light Source: 6V 20W halogen lamp or 3W LED Light with adjustable brightness.

Ordering Details:
