Multiviewing Microscope

• Viewing Head: Compensation Free Binocular Head, Inclined at 30 Degree.

• Eyepiece :WF 10X/22mm

• Nosepiece : Inverse Quintuple Nosepiece

• Objective: Infinity Achromatic Objective; 4X10X40X(s)100X(S)Oil

• Condenser: N.A. 1.25 Abbe condenser with iris diaphragm and filter

• Focusing: Coaxial Coarse & Fine Focus Adjustment, Fine Division 0.002mm

• Stage: 1. Double layer Mechanical stage. 2. Stage Sixe: 180mmX150mm 3. Moving Range : 75mmX50mm

• Kohler Illumination: External Illumination, Halogen Lamp 24V/ 100W

• Light Source: Halogen Bulb 12V30W. AC85V-230V Adjustable brightness.

• Illuminator: High-light Kohler illumination
