Upright Polarizing Microscope

Upright Polarizing Microscope

More Views

Upright Polarizing Microscope

Code:
Upright Polarizing Microscope
Model JPQR-500
Eyepiece WF 10X-20mm
Reticule Eyepiece WF 10X-20 mm (Cross Reticule 0.1mm)
Objective Infinity LONG WORKING DISTANCE PLAN Objective , 4X/0.1,10X/0.25, 20X/0.4 (S) and 40X/0.65 (S)
Head Seidentopf Binocular / Trinocular Head Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm
Nosepiece Quadruple
Revolving Mechanical Stage Rotatable 360°, Center Adjustable, Division 1°, Vernier division 6′
Condenser Abbe N.A. 1.25 with Iris Diaphragm
Focus Coaxial Coarse and Fine Focusing Knobs
Illumination LED 3.3W/3V, ISO – CE
Filter Amber, green and Neutral
Polarizing system Polarizing Analyzer, Bertrand Lens, λ Slip-Red,1/4?Slip,Quartz Wedge





Description

Details

Upright Polarizing Microscope
Model JPQR-500
Eyepiece WF 10X-20mm
Reticule Eyepiece WF 10X-20 mm (Cross Reticule 0.1mm)
Objective Infinity LONG WORKING DISTANCE PLAN Objective , 4X/0.1,10X/0.25, 20X/0.4 (S) and 40X/0.65 (S)
Head Seidentopf Binocular / Trinocular Head Inclined 30°, Rotatable 360°, Interpupilary Distance: 50-75mm
Nosepiece Quadruple
Revolving Mechanical Stage Rotatable 360°, Center Adjustable, Division 1°, Vernier division 6′
Condenser Abbe N.A. 1.25 with Iris Diaphragm
Focus Coaxial Coarse and Fine Focusing Knobs
Illumination LED 3.3W/3V, ISO – CE
Filter Amber, green and Neutral
Polarizing system Polarizing Analyzer, Bertrand Lens, λ Slip-Red,1/4?Slip,Quartz Wedge
