Projection Microscope

The body is well designed, inclined monocular with a sturdy base, overall height 500mm. The coarse motion is by rack and pinion arrangement. The dome is having precise screen and condenser 150mm. The illumination is with powerful condenser for high intensity of light, low voltage lamp to work with built-in-transformer. The object is projected on the optical glass screenhaving 150mm dia. The dome fits on the tube of microscope and can be rotated in all directions.

The optical combination is one-eyepiece huygenian 10X and two objectives achromatic 10X and 40X(SL). Total magnification 100-400X complete with detachable mechanical stage, illumination system 6v-20w with Halogen Lamp packed in thermocol packing.
