Series Metallurgical Industrial Microscope

Series Metallurgical Industrial Microscope

More Views

Series Metallurgical Industrial Microscope

Code:
Series Metallurgical Industrial Microscope

Flexible system, excellent imaging performance and stable system architecture.JQX-4RT series professional used in industrial testing and metallographic analysis.

JQX-4RT integrated bright-field, dark field, oblique illumination, polarizing, DIC differential interference and other observed functions, according to the practical application
 of functional selection.
Model No JQX-4R JQX-4RT
Alternative method of observation Bright field/Oblique illumination/polarizing/DIC Bright field/Dark field/Oblique illumination/polarizing/DIC /Transmission light
Optical system Infinity color corrected optical system
Eyepiece Hight eyepoint plan eyepiece PL10X/22
Viewing head 30°inclined gemel trinocular，reflect rate，binocular：trinocular=100：0or50:50
Objective LMPL infinity LWD Metallurgical objective 5X、10X、20X、50X、100X
Nosepiece Reversed Sextuple nosepiece，with DIC
Stage 4” mechanical stage，moving range 105x 105mm，with metal plate，right hand position X、Y moving hand wheel，the platform with interface 4” mechanical stage，moving range 105x 105mm，with glass plate, right hand position X、Y moving hand wheel，the platform with interface
Body Coaxial coarse and fine focus system, Coarse adjustment range 33 mm；precision of fine adjustment:0.001mm,，with coarse adjustment stop and tightness adjustment。Built-in wide voltage 90V-240V, single power supply output Coaxial coarse and fine focus system, Coarse adjustment range 33 mm；precision of fine adjustment:0.001mm,，with coarse adjustment stop and tightness adjustment。Built-in wide voltage 90V-240V, dual power supply output
Reflective illumination System With iris diaphragm and aperture diaphragm, both centers adjustable, with filter slot and polarizing device slot, switch rod with oblique lighting. Single high-power5W LED, white, light intensity continuously adjustable
With iris diaphragm and aperture diaphragm, both centers adjustable with filter slot and polarizing device slot, switch rod with oblique lighting.。12V100W halogen bulb，light intensity continuously adjustable (when selecting this group of lighting devices,
Transmission illumination system / Single high-power 5W LED, white, light intensity continuously adjustable. N.A.0.5 condenser wi
Description

Details

Series Metallurgical Industrial Microscope

Flexible system, excellent imaging performance and stable system architecture.JQX-4RT series professional used in industrial testing and metallographic analysis.

JQX-4RT integrated bright-field, dark field, oblique illumination, polarizing, DIC differential interference and other observed functions, according to the practical application
 of functional selection.
Model No JQX-4R JQX-4RT
Alternative method of observation Bright field/Oblique illumination/polarizing/DIC Bright field/Dark field/Oblique illumination/polarizing/DIC /Transmission light
Optical system Infinity color corrected optical system
Eyepiece Hight eyepoint plan eyepiece PL10X/22
Viewing head 30°inclined gemel trinocular，reflect rate，binocular：trinocular=100：0or50:50
Objective LMPL infinity LWD Metallurgical objective 5X、10X、20X、50X、100X
Nosepiece Reversed Sextuple nosepiece，with DIC
Stage 4” mechanical stage，moving range 105x 105mm，with metal plate，right hand position X、Y moving hand wheel，the platform with interface 4” mechanical stage，moving range 105x 105mm，with glass plate, right hand position X、Y moving hand wheel，the platform with interface
Body Coaxial coarse and fine focus system, Coarse adjustment range 33 mm；precision of fine adjustment:0.001mm,，with coarse adjustment stop and tightness adjustment。Built-in wide voltage 90V-240V, single power supply output Coaxial coarse and fine focus system, Coarse adjustment range 33 mm；precision of fine adjustment:0.001mm,，with coarse adjustment stop and tightness adjustment。Built-in wide voltage 90V-240V, dual power supply output
Reflective illumination System With iris diaphragm and aperture diaphragm, both centers adjustable, with filter slot and polarizing device slot, switch rod with oblique lighting. Single high-power5W LED, white, light intensity continuously adjustable
With iris diaphragm and aperture diaphragm, both centers adjustable with filter slot and polarizing device slot, switch rod with oblique lighting.。12V100W halogen bulb，light intensity continuously adjustable (when selecting this group of lighting devices,
Transmission illumination system / Single high-power 5W LED, white, light intensity continuously adjustable. N.A.0.5 condenser wi
Additional Information

Additional Information

Code No
