ProgRes® CCD SpeedXTcore indi Cameras

ProgRes® CCD SpeedXTcore indi Cameras

More Views

ProgRes® CCD SpeedXTcore indi Cameras

Code:
ProgRes® CCD SpeedXTcore indi Cameras



INFORMATION

  • SpeedXTcore – outstanding CCD live image speed for easy focusing
  • Fast FPS of 17 / 13 in full resolution of 3/5 mega pixel
  • Excellent image quality and high resolution
  • Perfect color reproduction
  • Easy and fast installation
  • Excellent price-performance ratio

  • Technical Specification
ProgRes SpeedXTcore indi Camera Type ProgRes SpeedXTcore 3 indi ProgRes SpeedXTcore 5 ind
Image Sensor 1/1.8” CCD 2/3” CCD
Color/Monochrome Color
Sensor Resolution(Max) 2080 x 1542 pixel[3.2MP] 2580 x 1944 pixel [5.0Mpix]
Pixel Size 3.45 µm2
A/D Convserion 12 Bit
Dynamic range 61 dB
Exposure times 30 µs...180s
Analog gain 1x..5x
Max.frame rate(image size) 17 fps [2080 x 1542]*
30 fps [1040 x 770]*		 13 fps [2580 x 1944]*
45 fps [640 x 484]
Image resolution Binning:
Progr.scan:		 2× ... 5× (SDK)
688 x 512		 2× ... 5× (SDK)
2576 × 1944 | 1288 × 972 | 640 × 484
Cooling No
Digital Interface USB 2.0, USB 3.0 conform
Optical Connection C-mount 0.5x /.63x recommended C-mount .63x recommended
Trigger In/Out NO
Voltage supply USB Powered
Power consumption Approx. 2.5W
Ambient conditions Temperature: +5°C....+35°C /Humidity: 5%....80% not condensing
Stock conditions Temperature: -10°C....+70°C
Dimensions (LxWxH) /Weight 89mm x 84mm x 93mm /approx 700g
Software Radical Capture Pro PC/MAC(Twain for PC),SDK on request
Hardware requirements Microsoft Windows XP / Vista / Windows 7/8/10 (32 & 64 bit) CPU: 3 GHz or 2 GHz multicore l
RAM: min. 1 GB l graphics: min. 256 MB l interface: IEEE1394 Firewire a (OHCI Standard), USB 2.0 or USB 3.0
Description

Details

ProgRes® CCD SpeedXTcore indi Cameras



INFORMATION

  • SpeedXTcore – outstanding CCD live image speed for easy focusing
  • Fast FPS of 17 / 13 in full resolution of 3/5 mega pixel
  • Excellent image quality and high resolution
  • Perfect color reproduction
  • Easy and fast installation
  • Excellent price-performance ratio

  • Technical Specification
ProgRes SpeedXTcore indi Camera Type ProgRes SpeedXTcore 3 indi ProgRes SpeedXTcore 5 ind
Image Sensor 1/1.8” CCD 2/3” CCD
Color/Monochrome Color
Sensor Resolution(Max) 2080 x 1542 pixel[3.2MP] 2580 x 1944 pixel [5.0Mpix]
Pixel Size 3.45 µm2
A/D Convserion 12 Bit
Dynamic range 61 dB
Exposure times 30 µs...180s
Analog gain 1x..5x
Max.frame rate(image size) 17 fps [2080 x 1542]*
30 fps [1040 x 770]*		 13 fps [2580 x 1944]*
45 fps [640 x 484]
Image resolution Binning:
Progr.scan:		 2× ... 5× (SDK)
688 x 512		 2× ... 5× (SDK)
2576 × 1944 | 1288 × 972 | 640 × 484
Cooling No
Digital Interface USB 2.0, USB 3.0 conform
Optical Connection C-mount 0.5x /.63x recommended C-mount .63x recommended
Trigger In/Out NO
Voltage supply USB Powered
Power consumption Approx. 2.5W
Ambient conditions Temperature: +5°C....+35°C /Humidity: 5%....80% not condensing
Stock conditions Temperature: -10°C....+70°C
Dimensions (LxWxH) /Weight 89mm x 84mm x 93mm /approx 700g
Software Radical Capture Pro PC/MAC(Twain for PC),SDK on request
Hardware requirements Microsoft Windows XP / Vista / Windows 7/8/10 (32 & 64 bit) CPU: 3 GHz or 2 GHz multicore l
RAM: min. 1 GB l graphics: min. 256 MB l interface: IEEE1394 Firewire a (OHCI Standard), USB 2.0 or USB 3.0
