Acetylene Cylinder 40L 150Bar

More Views

Acetylene Cylinder 40L 150Bar

Code:

Acetylene Cylinder 40L 150Bar

Product Description:

We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment. Our products have attained TUV and CE/TPED certifications.

Gas Cylinders Parameter

Model No	JGB5099
Working Medium	Acetone, Acetylene
Air tight text pressure	3.0MPa
Nominal Volume	25/40L
Design Wall Thickness	5.7mm
Outside Diameter	219mm
Acetone Filling Quantity	8.5/13.6kg
Maximum Amount of Acetylene Filling	4.5/7.2kg
Net Weight Cylinder	33/47.5kg
Cylinder total Strength	38.97" (990mm) / 52.55" (1335mm)
Maximum Working Temperature	40℃
Hydraulic Test Pressure	5.2MPa
Welding Factor	0.90

Description

Details

Acetylene Cylinder 40L 150Bar

Product Description:

We have implemented a strict and complete quality control system, which ensures that each product can meet quality requirements of customers. Besides, all of our products have been strictly inspected before shipment. Our products have attained TUV and CE/TPED certifications.

Gas Cylinders Parameter

Model No	JGB5099
Working Medium	Acetone, Acetylene
Air tight text pressure	3.0MPa
Nominal Volume	25/40L
Design Wall Thickness	5.7mm
Outside Diameter	219mm
Acetone Filling Quantity	8.5/13.6kg
Maximum Amount of Acetylene Filling	4.5/7.2kg
Net Weight Cylinder	33/47.5kg
Cylinder total Strength	38.97" (990mm) / 52.55" (1335mm)
Maximum Working Temperature	40℃
Hydraulic Test Pressure	5.2MPa
Welding Factor	0.90

Additional Information

Additional Information

Code	No
