Large Vaccine Carrier

Large Vaccine Carrier

More Views

Large Vaccine Carrier

Code:
Large Vaccine Carrier

Description:
MODEL  JAVC-44
TYPE Large Vaccine Carrier
WHO PIS Reference Number E-4/91-M
Vaccine Storage Capacity 1.6 Litres
Weight - fully loaded 4.2 Kgs.
Weight - empty (with empty icepacks 2.2 Kgs.
External Surface Material HDPE (High Density Polyethylene)
Internal Lining Material HIPS (High Impact Polystyrene)
Insulation Material CFC free Polyurethane
Insulation Thickness 35/40mm
External Dimensions (L x W x H) 25 x 25 x 30 cms
Internal dimensions (L x W x H) 16.5 x 16.5 x 22 cms
Vaccine Storage Dimensions 10 x 10 x 16 cms
Lid type & Fixings Removable
Number of Ice packs required 4
Number of Ice packs supplied 4
Ice-packs type E5/IP.2
Volume of Icepack 0.40 Litres
PERFORMANCE
Conforming to WHO Specifications
Cold Life Requirement as per WHO at 43 deg C ± 1 deg C without opening		 E4/VC.2

Min. 24 Hours
Actual Cold Life without opening 43 deg C ± 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 40 Hours 19 minutes
SHIPPING DIMENSIONS
Quantity in each carton (Nos.) 8
Gross Weight (approx.) 20.5 Kgs
Size of carton (L x W x H) (approx.) 53 x 53 x 64 cms
Volume of each carton (approx.) 0.18 CBM
No. of Units/20' container 1312
No. of Units/40' container 2624
No. of Units/40' High cube container 3040

Description

Details

Large Vaccine Carrier

Description:
MODEL  JAVC-44
TYPE Large Vaccine Carrier
WHO PIS Reference Number E-4/91-M
Vaccine Storage Capacity 1.6 Litres
Weight - fully loaded 4.2 Kgs.
Weight - empty (with empty icepacks 2.2 Kgs.
External Surface Material HDPE (High Density Polyethylene)
Internal Lining Material HIPS (High Impact Polystyrene)
Insulation Material CFC free Polyurethane
Insulation Thickness 35/40mm
External Dimensions (L x W x H) 25 x 25 x 30 cms
Internal dimensions (L x W x H) 16.5 x 16.5 x 22 cms
Vaccine Storage Dimensions 10 x 10 x 16 cms
Lid type & Fixings Removable
Number of Ice packs required 4
Number of Ice packs supplied 4
Ice-packs type E5/IP.2
Volume of Icepack 0.40 Litres
PERFORMANCE
Conforming to WHO Specifications
Cold Life Requirement as per WHO at 43 deg C ± 1 deg C without opening		 E4/VC.2

Min. 24 Hours
Actual Cold Life without opening 43 deg C ± 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 40 Hours 19 minutes
SHIPPING DIMENSIONS
Quantity in each carton (Nos.) 8
Gross Weight (approx.) 20.5 Kgs
Size of carton (L x W x H) (approx.) 53 x 53 x 64 cms
Volume of each carton (approx.) 0.18 CBM
No. of Units/20' container 1312
No. of Units/40' container 2624
No. of Units/40' High cube container 3040
