Small Vaccine Carrier

Small Vaccine Carrier

More Views

Small Vaccine Carrier

Code:
Small Vaccine Carrier
Description:
MODEL JADVC-24
TYPE Small Vaccine Carrier
WHO PIS Reference Number E-4/90-M
Vaccine Storgae Capacity 0.90 Litres
Weight - fully loaded 2.4 Kgs.
Weight - empty (with empty icepacks 1.4 Kgs.
External Surface Material HDPE (High Density Polyethylene)
Internal Lining Material HIPS (High Impact Polystyrene)
Insulation Material CFC free Polyurethane
Insulation Thickness 32/36mm
External Dimensions (L x W x H) 25 x 18 x 21 cms
Internal dimensions (L x W x H) 17 x 10 x 12 cms
Vaccine Storage Dimensions 17 x 10 x 5.3 cms
Lid type & Fixings Removable
Number of Ice packs required 2
Number of Ice packs supplied 2
Ice-packs type E5/IP.2
Volume of Icepack 0.40 Litres
PERFORMANCE
Conforming to WHO Specifications  Cold Life Requirement as per WHO at 43 deg C ± 1 deg C without opening E4/VC.1 Min. 16 Hours
Actual Cold Life without opening 43 deg C ± 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 19 Hours 25 minutes
SHIPPING DIMENSIONS
Quantity in each carton (Nos.) 12
Gross Weight (approx.) 21 Kgs.
Size of carton (L x W x H) (approx.) 55 x 55 x 48 cms
Volume of each carton (approx.) 0.15 CBM
No. of Units/20' container 2304
No. of Units/40' container 4608
No. of Units/40' High cube container 5616

Description

Details

Small Vaccine Carrier
Description:
MODEL JADVC-24
TYPE Small Vaccine Carrier
WHO PIS Reference Number E-4/90-M
Vaccine Storgae Capacity 0.90 Litres
Weight - fully loaded 2.4 Kgs.
Weight - empty (with empty icepacks 1.4 Kgs.
External Surface Material HDPE (High Density Polyethylene)
Internal Lining Material HIPS (High Impact Polystyrene)
Insulation Material CFC free Polyurethane
Insulation Thickness 32/36mm
External Dimensions (L x W x H) 25 x 18 x 21 cms
Internal dimensions (L x W x H) 17 x 10 x 12 cms
Vaccine Storage Dimensions 17 x 10 x 5.3 cms
Lid type & Fixings Removable
Number of Ice packs required 2
Number of Ice packs supplied 2
Ice-packs type E5/IP.2
Volume of Icepack 0.40 Litres
PERFORMANCE
Conforming to WHO Specifications  Cold Life Requirement as per WHO at 43 deg C ± 1 deg C without opening E4/VC.1 Min. 16 Hours
Actual Cold Life without opening 43 deg C ± 1 deg C as Tested by WHO approved Testing Lab, PSB, Singapore 19 Hours 25 minutes
SHIPPING DIMENSIONS
Quantity in each carton (Nos.) 12
Gross Weight (approx.) 21 Kgs.
Size of carton (L x W x H) (approx.) 55 x 55 x 48 cms
Volume of each carton (approx.) 0.15 CBM
No. of Units/20' container 2304
No. of Units/40' container 4608
No. of Units/40' High cube container 5616
