MNRU1102A Fixed Cradle

More Views

Code:

MNRU1102A Fixed Cradle

General Description

Mobile radiant heat warmer-fixed height
Mounted on 4 swivel castors (100mm) - 2 castors with brake
Baby tray with mattress along with head up/down facility and X-ray cassette holder
Mattress density approx. 21-25 kg/m3 and removable washable water proof cover
6mm thick - Transparent acrylic drop down and lockable side panel
Side tray for monitor and infusion rod for syringe pump/SS IV rod
2 shelves below baby bed for under surface Phototherapy and storage
FR grade moulded swivelling hood suspended above the table integrates heating element and overhead light
Heating element – Ceramic heater (650 W) with parabolic reflector, protected by metallic grid

Oxygenation:

Integrated support for 10L oxygen Cylinder
Oxygen regulator with pressure gauge, flow meter and humidifier bottle along with silicone tubing for delivery of oxygen from humidifier bottle to patient

Suction:

Integrated Slow Suction unit with Vacuum Regulator, Vacuum Gauge and Autoclavable
Fluid Jar 500ml (2 nos.) and Silicone tubing

Resuscitation:

Silicone manual Resuscitator size Infant (250ml) with 00 and 01 size face masks.
Laryngoscope - Penlight handle with size 0 and 1 straight blade
Silicone Airways size 000, 00 and 0

Temperature Controller A

Big red LED display for skin and air temperature
LED indicator for selected mode
LCD for alarm messages, selected mode, timer display, heater power (%), etc.
Integrated timer – 1 to 59 min with count-up and count-down feature
Temperature range – skin: 34 to 38°C (user pre-settable) air: room temperature to 39°C
Monitoring of skin temperature by means of sensor, range: 30 to 42°C
Heater output – 0 to 100% in increments of 5%
Control unit – Auto over-temperature cut-off with audio-visual alarms according to pre-set temperature to avoiding overheating
Display indicates system errors, sensor failure, alarm and visual message on LCD for high/low, over/under temperature for skin and air, heater failure, power control device failure.
Audio-Visual alarm for power failure

Description

MNRU1102A Fixed Cradle

General Description

Mobile radiant heat warmer-fixed height
Mounted on 4 swivel castors (100mm) - 2 castors with brake
Baby tray with mattress along with head up/down facility and X-ray cassette holder
Mattress density approx. 21-25 kg/m3 and removable washable water proof cover
6mm thick - Transparent acrylic drop down and lockable side panel
Side tray for monitor and infusion rod for syringe pump/SS IV rod
2 shelves below baby bed for under surface Phototherapy and storage
FR grade moulded swivelling hood suspended above the table integrates heating element and overhead light
Heating element – Ceramic heater (650 W) with parabolic reflector, protected by metallic grid

Oxygenation:

Integrated support for 10L oxygen Cylinder
Oxygen regulator with pressure gauge, flow meter and humidifier bottle along with silicone tubing for delivery of oxygen from humidifier bottle to patient

Suction:

Integrated Slow Suction unit with Vacuum Regulator, Vacuum Gauge and Autoclavable
Fluid Jar 500ml (2 nos.) and Silicone tubing

Resuscitation:

Silicone manual Resuscitator size Infant (250ml) with 00 and 01 size face masks.
Laryngoscope - Penlight handle with size 0 and 1 straight blade
Silicone Airways size 000, 00 and 0

Temperature Controller A

Big red LED display for skin and air temperature
LED indicator for selected mode
LCD for alarm messages, selected mode, timer display, heater power (%), etc.
Integrated timer – 1 to 59 min with count-up and count-down feature
Temperature range – skin: 34 to 38°C (user pre-settable) air: room temperature to 39°C
Monitoring of skin temperature by means of sensor, range: 30 to 42°C
Heater output – 0 to 100% in increments of 5%
Control unit – Auto over-temperature cut-off with audio-visual alarms according to pre-set temperature to avoiding overheating
Display indicates system errors, sensor failure, alarm and visual message on LCD for high/low, over/under temperature for skin and air, heater failure, power control device failure.
Audio-Visual alarm for power failure
