Full Automatic Tissue Paraffin/Wax Microtome

More Views

Code:

Full Automatic Tissue Paraffin/Wax Microtome

Features:

JRD-355AT Automatic Microtome is a full automatic microtome

It has two models for section: Automatic model and manual model.

When it is in automatic function, the user can release his hands and to do others.

It can simplify the technical difficulties of the section,    And reduce the operator labor intensity and make the work more efficiency.

Manual or automatic section model can quickly switch.

Switch arbitrarily between section and trimming.

Precise orientation of the specimen clamp.

All kinds of specimen clamp can be Exchanged freely.

Alarm system for horizontal and vertical stock limit , protection system for overload and Auto sleep.

The large waste tray can be disassembled easily.

Technical specification:

Model Number	JRD-355AT
Slice thickness range	0.5-100μm
Setting value	From 0.5-2 μm in 0.5μm increment.
	From 2-10 μm in 1μm increment .
	From 10-20 μm in 2 μm increment
	From 20-100 μm in 5 μm increment .
Trimming section range	0.5-999μm.
Speed of section	0-350mm/s adjustable
Horizontal specimen stroke	28mm
Vertical specimen stroke	60mm
Slip precision	±5%
Speed of fast-forward and back-forward	1 mm /s
Orientation of the specimen head	Axes X and Y 8°， axis Z 360°.
Voltage and power	AC220V/50Hz、or 110V/60Hz.
Dimension	500mm ( L) X 320mm (W) X 500 mm ( H)
Net weight	35 kg

Description

Full Automatic Tissue Paraffin/Wax Microtome

Features:

JRD-355AT Automatic Microtome is a full automatic microtome

It has two models for section: Automatic model and manual model.

When it is in automatic function, the user can release his hands and to do others.

It can simplify the technical difficulties of the section,    And reduce the operator labor intensity and make the work more efficiency.

Manual or automatic section model can quickly switch.

Switch arbitrarily between section and trimming.

Precise orientation of the specimen clamp.

All kinds of specimen clamp can be Exchanged freely.

Alarm system for horizontal and vertical stock limit , protection system for overload and Auto sleep.

The large waste tray can be disassembled easily.

Technical specification:

Model Number	JRD-355AT
Slice thickness range	0.5-100μm
Setting value	From 0.5-2 μm in 0.5μm increment.
	From 2-10 μm in 1μm increment .
	From 10-20 μm in 2 μm increment
	From 20-100 μm in 5 μm increment .
Trimming section range	0.5-999μm.
Speed of section	0-350mm/s adjustable
Horizontal specimen stroke	28mm
Vertical specimen stroke	60mm
Slip precision	±5%
Speed of fast-forward and back-forward	1 mm /s
Orientation of the specimen head	Axes X and Y 8°， axis Z 360°.
Voltage and power	AC220V/50Hz、or 110V/60Hz.
Dimension	500mm ( L) X 320mm (W) X 500 mm ( H)
Net weight	35 kg
